Image preview - the first page of the document
>> Download ky documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS Low impedance, 105C
KZH
Lower Z
@Newly innovative electrolyte is employed to minimize ESR
KZE
@Endurance with ripple current : 4,000 to 10,000 hours at 105C
@Non solvent resistant type Lower Z
@RoHS Compliant
KY
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +105C
Rated Voltage Range 6.3 to 100Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I=0.01CV or 3MA, whichever is greater.
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C after 2 minutes)
Dissipation Factor Rated voltage (Vdc) 6.3V 10V 16V 25V 35V 50V 63V 80V 100V
(tane) tanE (Max.) 0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.09 0.08
When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase. (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 6.3V 10V 16V 25V 35V 50V 63V 80V 100V
Characteristics Z(-25C)/Z(+20C) 4 3 2 2 2 2 2 2 2
(Max. Impedance Ratio)
Z(-40C)/Z(+20C) 8 6 4 3 3 3 3 3 3 (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for the specified period of time at 105C.
6.3 to 10Vdc F5 & 6.3 : 4,000hours F8 & 10 : 6,000hours F12.5 to 18 : 8,000hours
Time
16 to 100Vdc F5 & 6.3 : 5,000hours F8 & 10 : 7,000hours F12.5 to 18 : 10,000hours
Capacitance change [P25% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 500 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P25% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve (PET : Brown)
FP0.5
FP0.5
Fd
fD 5 6.3 8 10 12.5 16 18
fd 0.5 0.5 0.6 0.6 0.6 0.8 0.8
FD'
F 2.0 2.5 3.5 5.0 5.0 7.5 7.5
fD' FD+0.5max.
L' L+1.5max.
Vent L' 15min. 4min. (F5 to F10) (F12.5 to F18)
(Except F5 & F6.3)
Gas escape end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E KY- AAA E AA AAA M AAA N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 1.0MF:1R0,10MF:100,100MF:101)
Lead forming◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
