Image preview - the first page of the document
>> Download kzg documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS For computer motherboard
KZV
Lower Z
@Super low ESR/impedance capacitors due to very low resistivity electrolyte
KZJ
@Rated voltage range : 6.3 to 16V, Nominal capacitance range : 470 to 3,300MF
@Endurance with ripple current : 2,000 hours at 105C Lower Z
@The KZG series capacitors are designed for computer motherboards
@Non solvent-proof KZG
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +105C
Rated Voltage Range 6.3 to 16Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I=0.01CV or 3MA, whichever is greater.
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (Vdc) (at 20C after 2 minutes)
Dissipation Factor Rated voltage (Vdc) 6.3V 10V 16V
(tane) tanE (Max.) 0.22 0.19 0.16
When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase. (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 6.3V 10V 16V
Characteristics Z (-25C) / Z (+20C) 2 2 2
(Max. Impedance Ratio)
Z (-40C) / Z (+20C) 3 3 3 (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current for 2,000 hours at 105C.
Capacitance change [P25% of the initial measured value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C
without voltage applied.
Capacitance change [P25% of the initial measured value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve(PET : Brown)
FP0.5
Fd
fD 8 10
fd 0.6 0.6
FD'
F 3.5 5.0
fD' FD+0.5max.
Vent L' 15min 4min L' L+1.5max.
(F8 to F10)
Gas escape end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E KZG AAA E AA AAA M AAA N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 470MF:471, 2,200MF:222)
