Image preview - the first page of the document
>> Download lzm_snapin documenatation <<
Text preview - extract from the document
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS Long life snap-ins, 105C
LXM
@Endurance with ripple current : 7,000 hours at 105C
@Non solvent resistant type Longer life
@RoHS Compliant
LXQ
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -25 to +105C
Rated Voltage Range 160 to 450Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I[3 CV
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C after 5 minutes)
Dissipation Factor Rated voltage (Vdc) 160 to 400V 420 & 450V
(tane) tanE (Max.) 0.15 0.20 (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 160 to 400V 420 & 450V
Characteristics Z(-25C)/Z(+20C) 4 8
(Max. Impedance Ratio)
(at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 7,000 hours at 105C.
Capacitance change [P20% of the initial value
D.F. (tanE) [250% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P15% of the initial value
D.F. (tanE) [150% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : VS (F22 to F35) : Standard @Terminal Code : LI (F35)
Sleeve (PET : Brown) Negative mark PC board pin-out Sleeve (PET : Brown) Negative mark PC board pin-out
4.2P0.5
2-1.2B6
10
FD+1max.
FD+1max.
5P0.5
2-F2
*
4.0P0.5 14.2P1
LP2 LP2 4.5P1
Vent Vent
*FD=35mm : 3.5P0.5mm
The standard design has no plastic disc.
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E L XM AAA V S N AAA M AAA S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 47MF:470, 2,200MF:222)
Dummy terminal code
Terminal code (VS, LI)
Voltage code (ex. 160V:161, 315V:3B1, 450V:451)
Series code
Category
Please refer to "Product code guide (snap-in type)"
(1/3) CAT. No. E1001K
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS Long life snap-ins, 105C
?STANDARD RATINGS
Rated ripple Rated ripple
WV Cap Case size current WV Cap Case size current
tane Part No. tane Part No.
(Vdc) (mF) fDbL(mm) (Arms/ (Vdc) (mF) fDbL(mm) (Arms/
105c,120Hz) 105c,120Hz)
330 22B 25 0.15 1.11 ELXM161VSN331MP25S 220 22 B 25 0.15 0.90 ELXM221VSN221MP25S
390 22B 30 0.15 1.26 ELXM161VSN391MP30S 270 22 B 30 0.15 1.05 ELXM221VSN271MP30S
470 22B 30 0.15 1.39 ELXM161VSN471MP30S 330 22 B 35 0.15 1.19 ELXM221VSN331MP35S
470 25.4B 25 0.15 1.38 ELXM161VSN471MQ25S 330 25.4 B 25 0.15 1.16 ELXM221VSN331MQ25S
560 22B 35 0.15 1.55 ELXM161VSN561MP35S 390 22 B 40 0.15 1.33 ELXM221VSN391MP40S
560 25.4B 30 0.15 1.55 ELXM161VSN561MQ30S 390 25.4 B 30 0.15 1.29 ELXM221VSN391MQ30S
680 22B 40 0.15 1.75 ELXM161VSN681MP40S 470 22 B 45 0.15 1.49 ELXM221VSN471MP45S
680 25.4B 35 0.15 1.78 ELXM161VSN681MQ35S 470 25.4 B 35 0.15 1.48 ELXM221VSN471MQ35S
680 30B 25 0.15 1.74 ELXM161VSN681MR25S 470 30 B 25 0.15 1.45 ELXM221VSN471MR25S
820 22B 50 0.15 1.97 ELXM161VSN821MP50S 560 22 B 50 0.15 1.63 ELXM221VSN561MP50S
820 25.4B 40 0.15 2.01 ELXM161VSN821MQ40S 220 560 25.4 B 40 0.15 1.71 ELXM221VSN561MQ40S
160
820 30B 30 0.15 1.96 ELXM161VSN821MR30S 560 30 B 30 0.15 1.62 ELXM221VSN561MR30S
1,000 25.4B 45 0.15 2.27 ELXM161VSN102MQ45S 680 25.4 B 45 0.15 1.87 ELXM221VSN681MQ45S
1,000 30B 35 0.15 2.26 ELXM161VSN102MR35S 680 30 B 35 0.15 1.86 ELXM221VSN681MR35S
1,200 25.4B 50 0.15 2.54 ELXM161VSN122MQ50S 820 25.4 B 50 0.15 2.10 ELXM221VSN821MQ50S
1,200 30B 40 0.15 2.56 ELXM161VSN122MR40S 820 30 B 40 0.15 2.12 ELXM221VSN821MR40S
1,200 35B 30 0.15 2.52 ELXM161VSN122MA30S 820 35 B 30 0.15 2.08 ELXM221VSN821MA30S
1,500 30B 45 0.15 2.96 ELXM161VSN152MR45S 1,000 30 B 50 0.15 2.48 ELXM221VSN102MR50S
1,500 35B 35 0.15 2.89 ELXM161VSN152MA35S 1,000 35 B 40 0.15 2.46 ELXM221VSN102MA40S
1,800 30B 50 0.15 3.32 ELXM161VSN182MR50S 1,200 35 B 45 0.15 2.78 ELXM221VSN122MA45S
1,800 35B 40 0.15 3.30 ELXM161VSN182MA40S 1,500 35 B 50 0.15 3.20 ELXM221VSN152MA50S
2,200 35B 50 0.15 3.87 ELXM161VSN222MA50S 180 22 B 25 0.15 0.82 ELXM251VSN181MP25S
270 22B 25 0.15 1.00 ELXM181VSN271MP25S 220 22 B 30 0.15 0.95 ELXM251VSN221MP30S
330 22B 30 0.15 1.16 ELXM181VSN331MP30S 270 22 B 35 0.15 1.08 ELXM251VSN271MP35S
390 22B 30 0.15 1.26 ELXM181VSN391MP30S 270 25.4 B 25 0.15 1.05 ELXM251VSN271MQ25S
390 25.4B 25 0.15 1.26 ELXM181VSN391MQ25S 330 22 B 40 0.15 1.22 ELXM251VSN331MP40S
470 22B 35 0.15 1.42 ELXM181VSN471MP35S 330 25.4 B 30 0.15 1.19 ELXM251VSN331MQ30S
470 25.4B 30 0.15 1.42 ELXM181VSN471MQ30S 390 22 B 45 0.15 1.36 ELXM251VSN391MP45S
560 22B 40 0.15 1.59 ELXM181VSN561MP40S 390 25.4 B 35 0.15 1.35 ELXM251VSN391MQ35S
560 25.4B 30 0.15 1.55 ELXM181VSN561MQ30S 390 30 B 25 0.15 1.32 ELXM251VSN391MR25S
560 30B 25 0.15 1.58 ELXM181VSN561MR25S 470 22 B 50 0.15 1.49 ELXM251VSN471MP50S
680 22B 45 0.15 1.79 ELXM181VSN681MP45S 250 470 25.4 B 40 0.15 1.52 ELXM251VSN471MQ40S
680 25.4B 35 0.15 1.78 ELXM181VSN681MQ35S 470 30 B 30 0.15 1.49 ELXM251VSN471MR30S
180 680 30B 30 0.15 1.79 ELXM181VSN681MR30S 560 25.4 B 45 0.15 1.70 ELXM251VSN561MQ45S
820 25.4B 40 0.15 2.01 ELXM181VSN821MQ40S 560 30 B 35 0.15 1.69 ELXM251VSN561MR35S
820 30B 35 0.15 2.04 ELXM181VSN821MR35S 680 25.4 B 50 0.15 1.91 ELXM251VSN681MQ50S
1,000 25.4B 50 0.15 2.32 ELXM181VSN102MQ50S 680 30 B 40 0.15 1.93 ELXM251VSN681MR40S
1,000 30B 35 0.15 2.26 ELXM181VSN102MR35S 680 35 B 30 0.15 1.90 ELXM251VSN681MA30S
1,000 35B 30 0.15 2.30 ELXM181VSN102MA30S 820 30 B 45 0.15 2.19 ELXM251VSN821MR45S
1,200 30B 45 0.15 2.65 ELXM181VSN122MR45S 820 35 B 35 0.15 2.13 ELXM251VSN821MA35S
1,200 35B 35 0.15 2.58 ELXM181VSN122MA35S 1,000 35 B 40 0.15 2.46 ELXM251VSN102MA40S
1,500 30B 50 0.15 3.03 ELXM181VSN152MR50S 1,200 35 B 50 0.15 2.86 ELXM251VSN122MA50S
1,500 35B 40 0.15 3.01 ELXM181VSN152MA40S 100 22 B 25 0.15 0.67 ELXM3B1VSN101MP25S
1,800 35B 45 0.15 3.41 ELXM181VSN182MA45S 120 22 B 30 0.15 0.77 ELXM3B1VSN121MP30S
2,200 35B 50 0.15 3.87 ELXM181VSN222MA50S 150 22 B 30 0.15 0.86 ELXM3B1VSN151MP30S
220 22B 25 0.15 0.90 ELXM201VSN221MP25S 150 25.4 B 25 0.15 0.85 ELXM3B1VSN151MQ25S
270 22B 30 0.15 1.05 ELXM201VSN271MP30S 180 22 B 35 0.15 0.96 ELXM3B1VSN181MP35S
330 22B 30 0.15 1.16 ELXM201VSN331MP30S 180 25.4 B 30 0.15 0.96 ELXM3B1VSN181MQ30S
330 25.4B 25 0.15 1.16 ELXM201VSN331MQ25S 220 22 B 40 0.15 1.09 ELXM3B1VSN221MP40S
390 22B 35 0.15 1.29 ELXM201VSN391MP35S 220 25.4 B 30 0.15 1.06 ELXM3B1VSN221MQ30S
390 25.4B 30 0.15 1.29 ELXM201VSN391MQ30S 220 30 B 25 0.15 1.08 ELXM3B1VSN221MR25S
470 22B 40 0.15 1.46 ELXM201VSN471MP40S 270 22 B 45 0.15 1.24 ELXM3B1VSN271MP45S
470 25.4B 30 0.15 1.42 ELXM201VSN471MQ30S 270 25.4 B 35 0.15 1.23 ELXM3B1VSN271MQ35S
470 30B 25 0.15 1.45 ELXM201VSN471MR25S 270 30 B 30 0.15 1.23 ELXM3B1VSN271MR30S
315
560 22B 45 0.15 1.63 ELXM201VSN561MP45S 330 25.4 B 40 0.15 1.40 ELXM3B1VSN331MQ40S
560 25.4B 35 0.15 1.62 ELXM201VSN561MQ35S 330 30 B 35 0.15 1.42 ELXM3B1VSN331MR35S
200
560 30B 30 0.15 1.62 ELXM201VSN561MR30S 330 35 B 30 0.15 1.45 ELXM3B1VSN331MA30S
680 25.4B 40 0.15 1.83 ELXM201VSN681MQ40S 390 25.4 B 50 0.15 1.59 ELXM3B1VSN391MQ50S
680 30B 30 0.15 1.79 ELXM201VSN681MR30S 390 30 B 35 0.15 1.54 ELXM3B1VSN391MR35S
820 25.4B 45 0.15 2.06 ELXM201VSN821MQ45S 390 35 B 30 0.15 1.57 ELXM3B1VSN391MA30S
820 30B 35 0.15 2.04 ELXM201VSN821MR35S 470 30 B 45 0.15 1.81 ELXM3B1VSN471MR45S
1,000 30B 45 0.15 2.42 ELXM201VSN102MR45S 470 35 B 35 0.15 1.77 ELXM3B1VSN471MA35S
1,000 35B 30 0.15 2.30 ELXM201VSN102MA30S 560 30 B 50 0.15 2.03 ELXM3B1VSN561MR50S
1,200 30B 50 0.15 2.71 ELXM201VSN122MR50S 560 35 B 40 0.15 2.02 ELXM3B1VSN561MA40S
1,200 35B 40 0.15 2.70 ELXM201VSN122MA40S 680 35 B 45 0.15 2.29 ELXM3B1VSN681MA45S
1,500 35B 45 0.15 3.11 ELXM201VSN152MA45S 820 35 B 50 0.15 2.59 ELXM3B1VSN821MA50S
1,800 35B 50 0.15 3.50 ELXM201VSN182MA50S
(2/3) CAT. No. E1001K
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS Long life snap-ins, 105C
?STANDARD RATINGS
Rated ripple Rated ripple
WV Cap Case size current WV Cap Case size current
tane Part No. tane Part No.
(Vdc) (mF) fDbL(mm) (Arms/ (Vdc) (mF) fDbL(mm) (Arms/
105c,120Hz) 105c,120Hz)
100 22 B 25 0.15 0.67 ELXM351VSN101MP25S 56 22 B 25 0.20 0.50 ELXM421VSN560MP25S
120 22 B 30 0.15 0.77 ELXM351VSN121MP30S 68 22 B 30 0.20 0.58 ELXM421VSN680MP30S
120 25.4 B 25 0.15 0.76 ELXM351VSN121MQ25S 82 22 B 30 0.20 0.63 ELXM421VSN820MP30S
150 22 B 35 0.15 0.88 ELXM351VSN151MP35S 82 25.4 B 25 0.20 0.63 ELXM421VSN820MQ25S
150 25.4 B 30 0.15 0.88 ELXM351VSN151MQ30S 100 22 B 35 0.20 0.72 ELXM421VSN101MP35S
180 22 B 40 0.15 0.99 ELXM351VSN181MP40S 100 25.4 B 30 0.20 0.72 ELXM421VSN101MQ30S
180 25.4 B 30 0.15 0.96 ELXM351VSN181MQ30S 120 22 B 40 0.20 0.81 ELXM421VSN121MP40S
180 30 B 25 0.15 0.98 ELXM351VSN181MR25S 120 25.4 B 30 0.20 0.79 ELXM421VSN121MQ30S
220 22 B 45 0.15 1.12 ELXM351VSN221MP45S 120 30 B 25 0.20 0.80 ELXM421VSN121MR25S
220 25.4 B 35 0.15 1.11 ELXM351VSN221MQ35S 150 22 B 45 0.20 0.92 ELXM421VSN151MP45S
220 30 B 30 0.15 1.11 ELXM351VSN221MR30S 150 25.4 B 35 0.20 0.92 ELXM421VSN151MQ35S
350
270 25.4 B 40 0.15 1.26 ELXM351VSN271MQ40S 420 150 30 B 30 0.20 0.92 ELXM421VSN151MR30S
270 30 B 35 0.15 1.28 ELXM351VSN271MR35S 180 25.4 B 40 0.20 1.03 ELXM421VSN181MQ40S
330 25.4 B 45 0.15 1.40 ELXM351VSN331MQ45S 180 30 B 35 0.20 1.05 ELXM421VSN181MR35S
330 30 B 35 0.15 1.42 ELXM351VSN331MR35S 220 25.4 B 50 0.20 1.19 ELXM421VSN221MQ50S
330 35 B 30 0.15 1.45 ELXM351VSN331MA30S 220 30 B 35 0.20 1.16 ELXM421VSN221MR35S
390 30 B 40 0.15 1.60 ELXM351VSN391MR40S 220 35 B 30 0.20 1.18 ELXM421VSN221MA30S
390 35 B 35 0.15 1.61 ELXM351VSN391MA35S 270 30 B 45 0.20 1.38 ELXM421VSN271MR45S
470 30 B 50 0.15 1.86 ELXM351VSN471MR50S 270 35 B 35 0.20 1.34 ELXM421VSN271MA35S
470 35 B 40 0.15 1.85 ELXM351VSN471MA40S 330 30 B 50 0.20 1.56 ELXM421VSN331MR50S
560 35 B 40 0.15 2.02 ELXM351VSN561MA40S 330 35 B 40 0.20 1.55 ELXM421VSN331MA40S
680 35 B 50 0.15 2.36 ELXM351VSN681MA50S 390 35 B 45 0.20 1.74 ELXM421VSN391MA45S
68 22 B 25 0.15 0.55 ELXM401VSN680MP25S 470 35 B 50 0.20 1.96 ELXM421VSN471MA50S
82 22 B 30 0.15 0.63 ELXM401VSN820MP30S 47 22 B 25 0.20 0.46 ELXM451VSN470MP25S
100 22 B 30 0.15 0.70 ELXM401VSN101MP30S 56 22 B 30 0.20 0.52 ELXM451VSN560MP30S
100 25.4 B 25 0.15 0.70 ELXM401VSN101MQ25S 68 22 B 30 0.20 0.58 ELXM451VSN680MP30S
120 22 B 35 0.15 0.79 ELXM401VSN121MP35S 68 25.4 B 25 0.20 0.58 ELXM451VSN680MQ25S
120 25.4 B 30 0.15 0.79 ELXM401VSN121MQ30S 82 22 B 35 0.20 0.65 ELXM451VSN820MP35S
150 22 B 40 0.15 0.90 ELXM401VSN151MP40S 82 25.4 B 30 0.20 0.65 ELXM451VSN820MQ30S
150 25.4 B 30 0.15 0.88 ELXM401VSN151MQ30S 100 22 B 40 0.20 0.74 ELXM451VSN101MP40S
150 30 B 25 0.15 0.90 ELXM401VSN151MR25S 100 25.4 B 30 0.20 0.72 ELXM451VSN101MQ30S
180 22 B 45 0.15 0.99 ELXM401VSN181MP45S 100 30 B 25 0.20 0.73 ELXM451VSN101MR25S
180 25.4 B 35 0.15 1.01 ELXM401VSN181MQ35S 120 22 B 45 0.20 0.83 ELXM451VSN121MP45S
400 180 30 B 30 0.15 1.01 ELXM401VSN181MR30S 120 25.4 B 35 0.20 0.82 ELXM451VSN121MQ35S
220 25.4 B 40 0.15 1.14 ELXM401VSN221MQ40S 450 120 30 B 30 0.20 0.82 ELXM451VSN121MR30S
220 30 B 35 0.15 1.16 ELXM401VSN221MR35S 150 25.4 B 40 0.20 0.94 ELXM451VSN151MQ40S
270 25.4 B 50 0.15 1.32 ELXM401VSN271MQ50S 150 30 B 35 0.20 0.96 ELXM451VSN151MR35S
270 30 B 40 0.15 1.33 ELXM401VSN271MR40S 180 25.4 B 45 0.20 1.06 ELXM451VSN181MQ45S
270 35 B 30 0.15 1.31 ELXM401VSN271MA30S 180 30 B 35 0.20 1.05 ELXM451VSN181MR35S
330 30 B 45 0.15 1.52 ELXM401VSN331MR45S 180 35 B 30 0.20 1.07 ELXM451VSN181MA30S
330 35 B 35 0.15 1.48 ELXM401VSN331MA35S 220 30 B 40 0.20 1.20 ELXM451VSN221MR40S
390 30 B 50 0.15 1.69 ELXM401VSN391MR50S 220 35 B 35 0.20 1.21 ELXM451VSN221MA35S
390 35 B 40 0.15 1.68 ELXM401VSN391MA40S 270 30 B 50 0.20 1.41 ELXM451VSN271MR50S
470 35 B 45 0.15 1.91 ELXM401VSN471MA45S 270 35 B 40 0.20 1.40 ELXM451VSN271MA40S
560 35 B 50 0.15 2.14 ELXM401VSN561MA50S 330 35 B 45 0.20 1.60 ELXM451VSN331MA45S
390 35 B 50 0.20 1.79 ELXM451VSN391MA50S
?RATED RIPPLE CURRENT MULTIPLIERS
@Frequency Multipliers
Frequency(Hz) 50 120 300 1k 10k 50k
160 to 250Vdc 0.81 1.00 1.17 1.32 1.45 1.50
315 to 450Vdc 0.77 1.00 1.16 1.30 1.41 1.43
The endurance of capacitors is reduced with internal heating produced by ripple current at the rate of halving the lifetime with every 5C rise.
When long life performance is required in actual use, the rms ripple current has to be reduced.
(3/3) CAT. No. E1001K
