Image preview - the first page of the document
Elecap [radial thru-hole] CD11C Series


>> Download Elecap [radial thru-hole] CD11C Series documenatation <<

Text preview - extract from the document
Type CD11C Super-Miniature Aluminum Electrolytic Capacitors
Features and Applications
Load life of 1,000 hours at 85.
7mm L, Standard type.
Suitable for high-density electronic equipment, such as VTR, video camera, car radio, micro
cassette tape recorder, etc.
Performance and Characteristics
         Item                                          Characteristics
Operating temperature
                                                        -40+85
        range
 Rated voltage range                                     4100V
 Capacitance range                                      0.1330
