                     A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


BP Series
For horizontal deflection TV set.
Excellent life characteristics, high
frequency and compact size.
SPECIFICATIONS
             Item                                                    Performance Characteristics
 Category Temperature Range                                                   -25~+85
   Working Voltage Range                                                      25~50Vdc
    Capacitance Range                                                        2.2 ~ 10 F
   Capacitance Tolerance
