Image preview - the first page of the document



>> Download Elite [radial thru-hole] EM Series documenatation <<

Text preview - extract from the document

                        A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


EM Series
Low impedance, high ripple current and
miniature size with 7 to 9 mm height
SPECIFICATIONS
                 Item                                                        Performance Characteristics
  Category Temperature Range                                                        -40 ~ +105
      Working Voltage Range                                                          6.3 ~ 35Vdc
       Capacitance Range                                                             33 ~ 470 F
      Capacitance Tolerance
