Image preview - the first page of the document
Elite [radial thru-hole] LK Series


>> Download Elite [radial thru-hole] LK Series documenatation <<

Text preview - extract from the document
                   A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


LK Series
Downsize and high ripple current.
Load life: 4,000 hours at 105.
SPECIFICATIONS
           Item                                                       Performance Characteristics
 Category Temperature Range                                                  -25 ~ +105
  Working Voltage Range                                                      160 ~ 200Vdc
    Capacitance Range                                                         22 ~ 39 F
   Capacitance Tolerance
