Image preview - the first page of the document
Elite [radial thru-hole] LM Series


>> Download Elite [radial thru-hole] LM Series documenatation <<

Text preview - extract from the document
                         A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


LM Series
High ripple current capability.
High stability.
SPECIFICATIONS
                 Item                                                       Performance Characteristics
 Category Temperature Range                                                        -25 ~ +105
      Working Voltage Range                                                        200 ~ 450Vdc
       Capacitance Range                                                             1 ~ 68 F
      Capacitance Tolerance
