Image preview - the first page of the document
Elite [radial thru-hole] PS Series


>> Download Elite [radial thru-hole] PS Series documenatation <<

Text preview - extract from the document
                          A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


PS Series
Standard size Downsize
1,000 hours assured at 105
SPECIFICATIONS
               Item                                                              Performance Characteristics
 Category Temperature Range                             -40 ~ +105                                                     -25 ~ +105
     Working Voltage Range                              6.3 ~ 100Vdc                                                   160 ~ 450Vdc
      Capacitance Range                               0.1 ~ 22,000F                                                    0.47 ~ 470 F
     Capacitance Tolerance
