Image preview - the first page of the document



>> Download Elite [radial thru-hole] PV Series documenatation <<

Text preview - extract from the document

                        A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


PV Series
Downsize and high ripple current
Load life 2,000 ~ 5,000 hours at 105
SPECIFICATIONS
                Item                                                        Performance Characteristics

 Category Temperature Range                                                          -25 ~ +105

     Working Voltage Range                                                           200 ~ 450Vdc

      Capacitance Range                                                              6.8 ~ 470 F

     Capacitance Tolerance
