Image preview - the first page of the document
Elite [screw-terminal] SC Series


>> Download Elite [screw-terminal] SC Series documenatation <<

Text preview - extract from the document
                      A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


SC Series
High ripple, suitable to use in industrial power
supplies for inverter circuitry, etc.
SPECIFICATIONS
              Item                                                       Performance Characteristics
  Category Temperature Range                                                      -25 ~ +85
   Working Voltage Range                                                         200 ~ 450Vdc
     Capacitance Range                                                          820 ~ 33,000F
   Capacitance Tolerance
