Image preview - the first page of the document
Elite [snap-in] GM Series


>> Download Elite [snap-in] GM Series documenatation <<

Text preview - extract from the document
                    A L U M I N U M E L E C T R O LY T I C C A PA C I T O R S


GM Series
Large size for PCB board mounting hole type.

SPECIFICATIONS
            Item                                                      Performance Characteristics
  Category Temperature Range                       -40 ~ +85                                           -25 ~ +85
   Working Voltage Range                           16 ~ 100Vdc                                         160 ~ 450Vdc
     Capacitance Range                          820 ~ 68,000F                                          56 ~ 2,700 F
   Capacitance Tolerance
