                               Components for the Future



Aluminum Electrolytic Capacitor Series Table

                  Temperature Voltage Capacitance
Series Mounting                                   Lifetime              Features          Data File Size
                    Range     Range     Range
                   -40   85       10   100   470    68000   2000     PCB Snap-In
GPP    SNAP-IN
                   -25   85      160   450   47      2700   2000
                                                                                              49 KB
                                                                   Variable Case Sizes
                                                                   PCB Snap-In.10mm
                   -40   105      10   100   330    68000   2000
GMP    SNAP-IN
                   -25   105     160   450   33      2200   2000
                                                                        Pitch High            48KB
                                                                       Temperature
                                                                     General Purpose,
                   -40   85      6.3   400   0.1    22000   2000         Solvent
GPS    RADIAL
                   -25   85      450   450    1       47    2000    Proof. Suitable for
                                                                                              26 KB
                                                                          Taping
                   -55   105     6.3   100    0.1   22000   2000   High Temperature,
GMS    RADIAL      -40   105     160   400   0.47    470    2000     Solvent Proof,           24 KB
                   -25   105     450   450     1      47    2000   Suitable for Taping
                   -40   85      6.3   400   0.47   22000   2000
GPST    AXIAL
                   -25   85      450   450    1       33    2000
                                                                    Suitable for Taping       27 KB

                                                                   Wide Temperature
GMST    AXIAL      -40   105     6.3   100   0.47   6800    1000                              21 KB
                                                                    Suitable for Taping
                                                                   High Ripple Current
                                                                         Rating
FMEX   RADIAL      -55   105     6.3   63    0.47   15000   5000                              34 KB
                                                                   Wide Temperature
                                                                   Variable Case Sizes
                                                                     Miniature 7mm
GP7    RADIAL      -40   85      6.3   50    0.1     100    1000         Height               20 KB
                                                                      Solvent Proof
                                                                     Miniature 5mm
GP5    RADIAL      -40   85      4     50    0.1     220    1000         Height               22 KB
                                                                    Suitable for Taping
                                                                     Low Leakage
GPL    RADIAL      -40   85      10    50    0.1    1000    2000                              19 KB
                                                                       Anti-Solvent
                                                                        Bipolar
GPN    RADIAL      -40   85      6.3   100   0.1    6800    1000                              17 KB
                                                                       Anti-Solvent
MXM      SMD       -40   85      4     50    0.1     820    2000      Surface Mount           38 KB

MTM      SMD       -40   105     4     50    0.1     470    2000      Surface Mount           38 KB
