Image preview - the first page of the document



>> Download FPCAP [polymer thru-hole] Type RE - E5 Series documenatation <<

Text preview - extract from the document

Products / Radial Lead Type


                            Functional Polymer Aluminum Solid Electrolytic Capacitors



 E5 series
                                                                                     Ultra                                          Large
                                                                                    Low ESR               Low Profile
                                                                                                                                  Capacitance

                                                                                                                      RoHS
     Features                                                                                       Lead-free
                                                                                                                    Compliance
     By using Functional Polymer cathode, Frequency & Temp.
     characteristics are greatly improved.
        Low ESR at a high frequency range.
        High ripple current capability.
        Long life and high reliability.

     Applications
       Switching Power Supply and DC/DC Converter.
       Back up Power Supplies of CPU(VRM etc.)
       Miniature high Power Supply.

     Environmental Correspondence
     Any environmental hazardous substances are not used.
      The lead free of terminal plating (Sn 100%)

     Specifications
                                                         Characteristics
               Items
                                                              E5
       Operating Temp. Range                               - 55 to + 105
