Image preview - the first page of the document



>> Download FPCAP [polymer thru-hole] Type RE - R5 Series documenatation <<

Text preview - extract from the document

Products / Radial Lead Type


                              Functional Polymer Aluminum Solid Electrolytic Capacitors



     R5 series
                                                                                                                Ultra
                                                                                                               Low ESR

                                                                                                                             RoHS
     Features                                                                                           Lead-free
                                                                                                                           Compliance
     By using Functional Polymer cathode, Frequency & Temp.
     characteristics are greatly improved.
        Low ESR at a high frequency range.
        High ripple current capability.
        Long life and high reliability.

     Applications
       Switching Power Supply and DC/DC Converter.
       Back up Power Supplies of CPU(VRM etc.)
       Miniature high Power Supply.

     Environmental Correspondence
     Any environmental hazardous substances are not used.
      The lead free of terminal plating (Sn 100%)

     Specifications
                                                             Characteristics
                  Items
                                                                  R5
       Operating Temp. Range                                   - 55 to + 105
