Image preview - the first page of the document
>> Download Fulik Series Table documenatation <<
Text preview - extract from the document
Aluminum Electrolytic Capacitors Series Table.
Category Series Features Temperature Rated Voltage Capacitance Load Life
() (V.DC) (uF)
Miniature SM 5mm height standard -40 To +85 4 to 50 0.1 to 470 1000hrs
SX 7mm height standard -40 To +85 6.3 ~ 63 0.1 to 470 1000hrs
KF 5mm height, wide-temperature -40 To +105 4 to 50 0.1 to 100 1000hrs
SS 7mm height, high CV standard -40 To +85 6.3 ~ 63 0.1 to 470 1000hrs
KS 7mm high, wide-temperature -40 To +105 6.3 ~ 63 0.1 to 220 1000hrs
GR Standard , long life -40 To +85 6.3 to 450 0.1 ~ 33 000 2000hrs
GS Small size, long life -40 To +85 6.3 to 450 0.1 to 15000 2000hrs
GM General Purpose -40 To +85 6.3 to 450 0.1 ~ 33 000 1000hrs
KM Standard wide-temperature -40 To +105 6.3 to 450 0.1 to 10000 1000hrs
Low LF High-frequency, Low Impedance -40 To +105 6.3 ~ 450 0.47 ~ 15000 1000hrs
impedance GE Low impedance wide-temperature -40 To +105 6.3 to 450 0.47 ~ 15000 1000hrs
GF Long life, high frequency low the ESR -40 To +105 6.3 ~ 50 4.7 to 4700 2000hrs
Low leakage LM 5mm height, Low leakage current -40 To +85 6.3 ~ 63 0.1 to 100 1000hrs
DM Low leakage current, standard -40 To +85 6.3 to 100 0.1 to 3300 1000hrs
FM Low leakage, wide temperature -40 To +105 6.3 to 100 0.1 to 3300 1000hrs
SMD Aluminum Electrolytic Capacitors Series Table.
Temperature Rated Voltage Capacitance
Category Series Features Load Life
() (V.DC) (uF)
SMD Surface RVS Standard, 85 , 2000 hrs. - 40 to + 85 4 to 100 0.1 to 1500 2000hrs
Mount Type RVK Low leakage current 105 , 2000hrs. - 55 to + 105 6.3 ~ 50 0.1 to 330 2000hrs
RVW Wide Temperature 105 , 2000hours - 55 to + 105 6.3 to 100 4.7 to 1500 2000hrs
RVT Wide Temperature 105 , 1000hours - 55 to + 105 6.3 to 100 0.47 to 1500 1000hrs
RVE Lower Impedance, 105 , 1000hours. - 55 to + 105 6.3 ~ 50 0.1 to 1500 1000hrs
RVH Wide temperature 125 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
