Image preview - the first page of the document



>> Download Koolyn [screw-terminal] KLE15 Series documenatation <<

Text preview - extract from the document

                                  Koolyn Electronic CO., LIMITED

                           Tel: +86-755-86659586 15914153748             Fax:+86-755-86659586
                                      KLE15 Screw Terminal Aluminum Electrolytic Capacitor 85


1.FEATURES:
      Load life 5000 Hrs at 85

      Used in industrial welding machines, variable frequency speed controller, servo
      control, switching power supply, PC machine power supplies, industrial power
      supplies.

2.(SPECIFICATIONS):
 Item                                                       Performance Characteristics
 Operating
                                                                    -40 to +85
 Temperature Range
 Rated voltage Range                                              400V to 450VDC

 Capacitance Range                                                1000to 10000F
 Capacitance
