Image preview - the first page of the document
>> Download KapuCon Series Table documenatation <<
Text preview - extract from the document
LV 85 -40 to +85 4-50V 0.1-1500uF 0.01CV or 3uA 2000 13
EV 105 -40 to +105 6.3-50V 0.1-1500uF 0.01CV or 3uA 1000 15
SMD
HV -40 to +105 6.3-50V 0.1-1500uF 0.01CV or 3uA 2000 17
JV 3000 -40 to +105 6.3-50V 0.1-1000uF 0.01CV or 3uA 3000 19
RL -55 to +105 2.5-16V 180-3500uF 0.02CV uA 2000 21
RG/RS -55 to +105 2.5-25V 39-3500uF 0.02CV uA 2000 23
Polymer
RF -55 to +105 2.5-10V 180-3500uF 0.02CV uA 2000 25
SM 57mm -40 to +85 4-63V 0.1-470uF 0.01CV or 3uA 1000 27
-40 to +85 6.3-100V 0.1-33000uF 0.01CV or 3uA
GM 85 2000 30
-25 to +85 160-450V 0.47-560uF 0.03CV uA
SK 57mm -40 to +105 4-63V 0.1-470uF 0.01CV or 3uA 1000 33
-40 to +105 6.3-100V 0.1-22000uF 0.01CV or 3uA
KS 105 2000 36
-25 to +105 160-450V 0.47-470uF 0.03CV uA
-40 to +85 6.3-100V 0.1-3300uF
NP 0.03CV or 3uA 2000 39
-25 to +85 160-250V 0.47-47uF
-40 to +105 6.3-100V 0.1-3300uF
NK 0.03CV or 3uA 2000 42
-25 to +105 160-250V 0.47-47uF
-40 to +105 6.3-100V 0.47-15000uF 0.01CV or 3uA
KH 2000-5000 44
-25 to +105 160-450V 0.47-330uF 0.04CV+100uA
-40 to +105 10-50V 6.8-3300uF 0.01CV or 3uA
Radial KR 5000-10000 48
-25 to +105 160-450V 6.8-220uF 0.04CV+100uA
-40 to +125 10-100V 0.47-1000uF 0.01CV or 3uA
TH 1000-2000 50
-25 to +125 160-350V 1-100uF 0.02CV uA
TE -40 to +130 10-50V 10-4700uF 0.01CV or 3uA 2000-3000 52
KE -55 to +105 6.3-63V 0.47-15000uF 0.01CV or 3uA 2000-3000 54
KF -55 to +105 6.3-63V 1-10000uF 0.01CV or 3uA 3000-5000 57
LOW ESR
KG -55 to +105 6.3-50V 22-6800uF 0.01CV or 3uA 5000-8000 59
KL -55 to +105 6.3-50V 47-6800uF 0.01CV or 3uA 7000-10000 62
KY -40 to +105 6.3-25V 220-3300uF 0.01CV or 3uA 2000 65
LL -40 to +105 4-63V 0.1-2200uF 0.002CVor 0.4uA 2000 67
RL -40 to +105 160-450V 1.0-220uF 0.03CV+3uA 5000 69
RZ -40 to +105 160-450V 1-220uF 0.03CV+3uA 8000-10000 71
RF -20 to +55 330/350V 100-450uF 1*C uA 5000 73
-40 to +85 10-100V 470-68000uF
LM 85 0.02CV uA 2000 74
-25 to +85 160-450V 47-3300uF
Snap-in -40 to +105 10-100V 470-68000uF
HM 105 0.02CV uA 2000 77
-25 to +105 160-450V 33-4700uF
-40 to +85 16-100V 3300-1000000uF
RP 85 0.02CV uA 2000 80
-25 to +85 160-450V 220-68000uF
Screw -40 to +105 16-100V 1500-1000000uF
RH 105 0.02CV uA 2000 82
-25 to +105 160-400V 220-100000uF
3/87
