Image preview - the first page of the document



>> Download Hitano Series Table documenatation <<

Text preview - extract from the document

Series      Features        Temperature        Voltage (V.DC)   Capacitance (uF)   Life (Hrs)

                             Conductive Polymer Type
EVS           V Chip         -55~+105                2.5~20         22~1500          2000

ERS           Radial         -55~+105                2.5~20         22~1500          2000
                               V-chip (Surface Mount Type)

 ELV     General Purpose      -40~+85                4~450         0.1~6800          2000

EHV        Wide Temp.        -40~+105                6.3~450       0.1~6800          2000

ENV         Non Polar         -40~+85                6.3~50         0.1~47           2000

EKV       Low Leakage         -40~+85                6.3~50         0.1~330          2000

 EZV     Low Impedance       -40~+105                6.3~50        0.1~1000          2000

                              General Purpose (Radial Type)

ECR         Standard          -40~+85                6.3~450      0.47~10000         2000

EHR        Wide Temp.        -40~+105                6.3~450      0.47~10000         2000

ENR         Non Polar        -40~+105                10~100        0.47~1000         1000

 E5R      Ultra Miniature    -40~+105                 4~50          0.1~220          1000

EMR      Super Miniature     -40~+105                 4~63         0.47~470          1000

                                   Low Leakage Type

ELR         Standard         -40~+105                6.3~63        0.47~1000         1000

EMRL     Super Miniature     -40~+105                6.3~63        0.47~100          1000

                                  Low Impedance Type

EXR         Standard         -40~+105                6.3~450      0.47~15000       2000~5000

ESX        Low Profile       -55~+105                6.3~63        0.47~4700         5000

ESG        For Ballast       -25~+105                160~450        10~220           5000

                                 SNAP IN Terminal Type

 ELP        Standard          -40~+85                16~450        47~47000          2000

EHP        Wide Temp.        -40~+105                16~450       330~47000          2000

EHL      Low Impedance       -40~+105                10~400        68~47000          5000

                                        Axial Type

ECA         Standard          -40~+85                10~100       0.47~10000         2000
