      Aluminum Electrolytic Capacitor Series Table
                       FEATURES               TEMPERATURE           RATED           CAPACITANCE       SHAPE OR
       SERIES
                     APPLICATIONS                RANGE            VOLTAGE(V)          RANGE(F)          TYPE

CD11(GS)SERIES     Miniature standard       -40~+85             6.4~450           0.1~10000           Radial


CD110(PT) SERIES   Color TV standard        -40~+85/-25~+85     6.3~100/100~205   0.1~10000/1.0~205   Radial


CD71(NP) SERIES    Non-polar standard       -40~+85             6.3~100           0.47~6800           Radial


CD72(BP) SERIES    Non-polar speaker        -40~+85             10~100            0.47~47             Radial


CD11L(ML) SERIES   Low leakage current      -40~+85             6.3~100           0.1~4700            Radial


CD11T(MT) SERIES   Long life                -40~+85             6.3~100           1.0~4700            Radial

CD110X(SX)(7mm)    Super miniature 7mm
                                            -40~+105            6.3~63            0.1~470             Radial
SERIES             height
CD11W(LM) (5mm)    Super miniature 5mm
                                            -40~+105            4~50              0.1~330             Radial
SERIES             height
                   For horizontal
CDS(HX) SERIES                              -40~+85             10~100            0.47~47             Radial
                   deflection
CD81(TR)(105
