Image preview - the first page of the document
![Jakec [snap-in] CD294 (SK) Series](/pics/5c1ee0199fd75.gif)
>> Download Jakec [snap-in] CD294 (SK) Series documenatation <<
Text preview - extract from the document
CD294(SK) SERIES
Load life of 2000 hours at 105 400 400 400
High ripple current
Smaller Size
PCB Mounting
SPECIFCATIONS
Item Characteristics
Operating Temperature Range( ) -40 - + 105
Capacitance Tolerance(25 ,120Hz) + 20%
-
0.01CV or 1.2mA whichever is smaller.(at 25 ,after 5 minutes)
Leakage Current( A) C:Nominal Capacitance( F)V:Rated Voltage(V)
Rated Voltage(V) 10 16 25 35 50 63~100 160~200 250~400
Dissipation Factor(25 ,120Hz) tan 0.45 0.35 0.30 0.25 0.20 0.15 0.12 0.15
Rated Voltage(V) 10,16 25 35 50,63 80,100 160~200 250~400
Temperature Stability(120Hz) Z-25 /Z+20 4 3 3 2 2 3 4
Impedance Ratio
Z-40 /Z+20 15 10 8 6 5 6
Time 2000 hours
Leakage Current Not more than the specified value.
Load Life(+105 ) Capacitance Change Within + 20% of the initial value.
Dissipation Factor Not more than 200% of the specified value.
Shelf Life(+105 ) 500 hours.No voltage applied.After test:U,to be applied for 60 minutes,24 to 48 hours before measurement.
DIMENSIONS MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Vant Sleeve 2- 2 50 120 1K 10K 20K
1.
0
10
50 0.95 1 1.10 1.15 1.15
0.
D-1max
1
6.3~100 0.95 1 1.16 1.30 1.33
160 0.90 1 1.20 1.50 1.55
1+2max Negative
Temperature coefficient
6.3 1 Temperature( ) +40 +55 +70 +85 +105
Factor 2.7 2.5 2.1 1.7 1.0
22
CD294(SK)
ALUMINUM ELECTROLYTIC CAPACITORS
STANDARD RATINGS
10 16 25 35 50 63 80 100
WV(V)
Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple
D L(mm) uF mArms uF mArms uF mArms uF mArms uF mArms uF mArms uF mArms uF mArms
22 25 6800 1.5 4700 1.4 3300 1.3 2200 1.1 1200 0.96 820 0.92 560 0.76 390 0.64
22 30 10000 1.9 6800 1.8 4700 1.6 2700 1.3 1800 1.2 1200 1.2 820 0.96 560 0.80
22 35 12000 2.1 8200 2.0 5600 1.8 3900 1.6 2200 1.4 1500 1.3 1000 1.1 680 0.92
22 40 15000 2.5 10000 2.3 6800 2.0 4700 1.9 2700 1.6 1800 1.5 1200 1.2 820 1.0
22 50 18000 2.8 15000 2.9 10000 2.6 6800 2.4 - - 2200 1.7 1800 1.6 1200 1.3
25 25 8200 1.7 6800 1.8 4700 1.6 3300 1.3 1800 1.2 1200 1.1 820 0.96 560 0.80
25 30 12000 2.1 10000 2.2 5600 1.8 3900 1.6 2700 1.5 1500 1.3 1000 1.1 680 0.92
25 35 15000 2.5 12000 2.5 8200 2.2 5600 2.0 3300 1.8 1800 1.5 1500 1.4 1000 1.1
25 40 18000 2.8 15000 2.9 10000 2.6 6800 2.3 - - - - 1800 1.6 - -
25 50 - - 18000 3.3 12000 2.9 8200 2.7 5600 2.5 3300 2.2 2200 1.8 1500 1.5
30 25 12000 2.2 10000 2.3 6800 2.0 4700 1.9 2700 1.6 1500 1.4 1200 1.3 820 1.0
30 30 18000 2.8 12000 2.6 8200 2.3 5600 2.1 3300 1.8 2200 1.7 1500 1.5 1000 1.2
30 35 22000 3.2 18000 3.3 12000 2.9 8200 2.9 4700 2.3 2700 2.0 1800 1.6 1200 1.4
30 40 - - 22000 3.7 15000 3.3 10000 3.0 5600 2.5 3300 2.3 2200 1.9 1500 1.6
30 50 - - - - 18000 3.8 12000 3.4 6800 2.9 4700 2.8 3300 2.3 2200 2.0
35 25 15000 2.6 12000 2.7 8200 2.4 5600 2.2 3300 1.8 2200 1.8 1500 1.5 1000 1.3
35 30 22000 3.3 18000 3.4 12000 3.0 8200 2.8 4700 2.4 2700 2.1 2200 1.9 1200 1.4
35 35 - - 22000 3.9 15000 3.5 10000 3.1 5600 2.7 - - 2700 2.2 1800 1.8
35 40 - - - - 18000 3.9 12000 3.5 6800 3.0 4700 2.9 3300 2.4 2200 2.0
35 50 - - - - - - 18000 4.5 10000 3.8 6800 3.6 4700 3.2 2700 2.3
160 180 200 250 315 350 400
WV(V)
Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple
D L(mm) uF mArms uF mArms uF mArms uF mArms uF mArms uF mArms uF mArms
22 25 180 0.65 180 0.65 150 0.60 100 0.45 56 0.34 56 0.37 39 0.32
22 30 270 0.83 220 0.75 220 0.76 150 0.58 82 0.43 82 0.47 56 0.39
22 35 330 0.94 270 0.86 270 0.87 180 0.65 120 0.53 100 0.53 68 0.45
22 40 390 1.1 390 1.1 330 0.99 220 0.75 150 0.61 120 0.60 82 0.51
22 50 560 1.3 470 1.2 470 1.2 330 0.96 180 0.71 180 0.78 120 0.64
25 25 270 0.82 220 0.75 220 0.76 150 0.58 82 0.42 68 0.43 56 0.40
25 30 390 1.1 330 0.96 270 0.87 220 0.73 120 0.53 100 0.54 68 0.48
25 35 470 1.2 390 1.1 390 1.1 270 0.83 150 0.62 120 0.61 100 0.57
25 40 560 1.3 470 1.2 470 1.3 330 0.95 - - 180 0.77 120 0.63
25 50 820 1.7 680 1.5 560 1.4 470 1.2 270 0.89 220 0.89 150 0.75
30 25 390 1.1 330 1.0 270 0.92 220 0.77 120 0.56 100 0.57 82 0.53
30 30 560 1.3 470 1.2 390 1.1 270 0.88 180 0.71 150 0.72 100 0.61
30 35 680 1.5 560 1.4 560 1.4 390 1.1 220 0.80 180 0.82 150 0.77
30 40 620 1.7 680 1.6 680 1.6 470 1.2 270 0.92 220 0.93 180 0.87
30 50 1000 2.0 1000 2.0 820 1.8 560 1.4 390 1.2 330 1.2 220 1.0
35 25 470 1.3 390 1.2 390 1.2 270 0.93 180 0.74 150 0.77 100 0.65
35 30 680 1.6 560 1.5 560 1.5 390 1.2 220 0.84 220 0.97 150 0.83
35 35 820 1.8 820 1.8 680 1.7 470 1.3 330 1.1 270 1.1 180 0.93
35 40 1000 2.0 1000 2.1 820 1.9 560 1.5 390 1.2 330 1.3 220 1.1
35 50 1500 2.6 1200 2.4 1200 2.4 820 1.9 470 1.4 470 1.6 330 1.3
23
