Image preview - the first page of the document
![OST [snap-in] SPH series](/pics/5c2dccbf8e04c.gif)
>> Download OST [snap-in] SPH series documenatation <<
Text preview - extract from the document
SPH Series
STANDARD RATINGS
V 10 16 25 35 50 63 80 100
DxL Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple
(mm) uF Arms uF Arms uF Arms uF Arms uF Arm s uF Arm s uF Arm s uF Arm s
22x25 10000 1.72 6800 1.68 47 00 1.55 33 00 1.39 1800 1.28 1200 1.05 10 00 1.06 680 0.95
22x30 12000 2.03 8200 1.92 56 00 1.67 39 00 1.57 2200 1.50 1500 1.24 12 00 1.29 820 1.13
22x35 15000 2.14 12000 2.1 6800 1.89 47 00 1.82 3300 1.69 2200 1.70 1800 1.63 12 00 1.55
22x40 18000 2.34 15000 2.28 82 00 2.13 68 00 2.33 3900 1.96 2700 1.89 22 00 1.94 15 00 1.78
22x45 22000 2.46 10000 2.52 4700 2.23 3300 2.16 27 00 2.17 18 00 2.03
22x50 27000 3.05 18000 2.96 12000 2.67 8200 2.65 5600 2.58
25x25 12000 1.87 10000 1.81 68 00 1.72 4700 1.53 2700 1.56 1800 1.40 1500 1.31 10 00 1.37
25x30 15000 1.98 12000 1.92 82 00 2.16 56 00 1.85 3300 1.74 2200 1.66 18 00 1.65 12 00 1.54
25x35 22000 2.41 15000 2.38 10000 2.45 68 00 2.15 4700 2.32 2700 1.96 22 00 1.74 1500 1.76
25x40 27000 2.86 18000 2.82 12000 2.61 82 00 2.53 5600 2.56 3900 2.37 27 00 2.08 18 00 2.06
25x45 33000 3.18 22000 3.26 15000 3.06 10000 2.87 6800 3.12 3300 2.51 2200 2.43
25x50 27000 3.55 12000 3.26 4700 2.84 3900 2.88 2700 2.72
30x25 18000 2.12 12000 2.15 82 00 1.97 68 00 2.15 3900 1.77 2700 1.67 22 00 1.84 1500 1.82
30x30 22000 2.39 15000 2.35 10000 2.46 82 00 2.56 4700 2.08 3300 2.12 27 00 2.07 18 00 2.02
30x35 33000 3.24 22000 3.13 15000 2.93 10000 2.87 6800 2.83 3900 2.47 3300 2.50 2200 2.32
30x40 39000 3.62 27000 3.65 18000 3.45 12000 3.05 8200 3.47 4700 2.74 3900 2.77 2700 2.76
30x45 47000 3.96 33000 3.98 22000 3.85 15000 3.53 4700 3.15 3300 3.09
30x50 39000 4.64 10000 3.82 6800 3.50 5600 3.68 3900 3.45
35x30 33000 3.11 22000 3.06 15000 2.97 12000 2.99 4700 2.74 3300 2.29 2200 2.43
35x35 39000 3.49 27000 3.69 18000 3.64 15000 3.49 5600 2.95 4700 3.12 2700 2.79
35x40 47000 3.98 39000 4.62 18000 4.09 6800 3.43 5600 3.74 3900 3.54
35x45 56000 4.88 47000 5.34 27000 4.59 22000 4.76 8200 3.89 68 00 3.70 4700 3.71
35x50 33000 5.37 10000 4.17 8200 3.78 5600 3.96
V 160 200 250 300 350 400 420 450
DxL Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple Cap Ripple
(mm) uF Arms uF Arms uF Arms uF Arms uF Arms uF Arms uF Arms uF Arms
22x25 330 1.25 270 1.05 180 0.95 100 0.58 10 0 0.58 68 0.51 68 0.48 56 0.42
22x30 470 1.40 330 1.15 220 1.07 150 0.75 120 0.71 100 0.63 100 0.60 68 0.51
22x35 560 1.52 390 1.26 270 1.17 180 0.84 15 0 0.77 120 0.68 120 0.62 82 0.58
22x40 680 1.77 470 1.53 330 1.33 220 0.97 18 0 0.83 150 0.84 150 0.81 100 0.68
22x45 820 2.08 560 1.64 390 1.51 270 1.05 22 0 0.97 180 0.93 180 0.90 120 0.76
22x50 680 1.70 470 1.62 330 1.15 27 0 1.05 220 1.04 220 1.00 150 0.81
25x25 470 1.58 330 1.15 220 0.98 150 0.71 120 0.70 100 0.68 100 0.63 68 0.61
25x30 560 1.71 470 1.26 330 1.25 220 0.96 15 0 0.80 150 0.84 150 0.80 82 0.64
25x35 680 1.95 560 1.65 390 1.48 270 1.07 22 0 0.97 180 0.93 180 0.90 120 0.79
25X40 820 2.15 680 1. 87 470 1.75 330 1.12 27 0 1.07 220 1.03 220 1.00 150 0.89
25x45 1000 2.45 820 1.97 560 1.80 390 1.33 33 0 1.18 270 1.12 270 1.08 180 0.98
25x50 12 00 2.55 1000 2.12 680 2.04 390 1.33 330 1.25 330 1.22 220 1.08
30x25 680 1.71 470 1.26 330 1.31 220 1.07 18 0 0.89 150 0.76 150 0.72 100 0.64
30x30 820 1.95 680 1.65 470 1.45 270 1.25 22 0 0.97 180 0.87 180 0.83 120 0.81
30x35 1000 2.45 820 2.15 560 1.89 330 1.41 33 0 1.26 220 1.13 220 1.10 180 1.16
30x40 1200 2.80 1000 2.40 680 2.08 470 1.63 39 0 1.45 270 1.27 270 1.25 220 1.39
30x45 1500 3.23 1200 2.55 820 2.25 560 1.90 47 0 1.48 330 1.40 330 1.36 270 1.44
30x50 1800 3.36 1000 2.43 560 1.67 390 1.61 390 1.56 330 1.55
35x25 1000 2.11 270 1.07 27 0 1.14 220 1.03 220 1.03 150 0.71
35x30 1200 2.45 820 2.15 680 1.95 390 1.41 33 0 1.16 270 1.13 180 0.82
35x35 1500 3.03 1000 2.45 820 2.10 470 1.87 39 0 1.66 330 1.47 270 1.42 270 1.16
35X40 1800 3.12 1500 2.98 1000 2.25 560 2.02 560 1.88 390 1.82 330 1.78 330 1.39
35X45 2200 3.46 1200 2.42 680 2.11 680 1.95 470 1.98 390 1.95 390 1.65
35x50 2700 3.90 1800 3.28 1500 2.86 820 2.27 560 2.05 470 2.01 470 1.78
Ripple Current: A(rms) at 120Hz, 105◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
