Image preview - the first page of the document
![LH NOVA-Fenghua [non-polar thru-hole] HA Series](/pics/5c2dccf6e3f50.gif)
>> Download LH NOVA-Fenghua [non-polar thru-hole] HA Series documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR(CD71 NP)
HA FEATURE
: 85 1000 Life time:85 1000 hours
Non-polarity
Suited for horizontal defluxion correction scan adjustment
SPECIFICATIONS
Item Performance Characteristics
25V.DC-50V.DC
Operating Temperature Range
-40 ~+85
Rated Voltage Range
1 F 10 F
Nominal Capacitance Range
20%(M,+20 ,120Hz)
Capacitance Tolerance
2 :I 0.2CV( A)
After application of rated voltage for 2 minutes :I 0.2CV 20
C: ( F); C: Nominal Capacitance in F;
Leakage Current
V: (V) V: Rated Working Voltage in V
(tan )
( 20 ,120Hz) 0.05
Dissipation Factor
C/C+20 10%
Temperature Stability Capacitance change shall be within 10% of the value at +20 over operating temperature range.
+85 12V 1000X2 :
After application of DC 12V and ripple current at +85 for 1000 2 hours ,
Capacitors meet the characteristics requirements measured at +20 listed below
15%
Capacitance Change Within 15% of the initial measured value
Load Life
Leakage current Less than the initial specified value
200%
Tan Less than 200% of the initial specified value
+85 1000
After leaving capacitors under no load at +85 for 1000 hours, capacitors meet the
Shelf Life
characteristics listed above
HA
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
Nominal
Capacitance 1.0(1R0) 1.5(1R5) 2.2(2R2) 3.3(3R3) 4.7(4R7) 6.8(6R8) 8.2(8R2) 10(100)
10X20 10X20 12.5X20 16X25 16X25 16X30 16X35 18X35
Case Size
Max Ripple Current 1.8 2.0 3.3 4.5 5.8 7.8 9.0 9.5
(AP-P)at85 ,15.75KHz)
CASE SIZE TABLE
D 10 12.5 16 18
F 0.5 5.0 7.5
d 0.1 0.6 0.8
2.0
