Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] LF Series](/pics/5c2dcd0854284.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] LF Series documenatation <<
Text preview - extract from the document
LF FEATURE
: 105 5000
Life time:105 5000 hours ( D 12.5 )
Low impedance
For switching power supplies and other industrial
electronic products applications
SPECIFICATIONS
Item Performance Characteristics
6.3V.DC 250V.DC
Rated Voltage Range
-55 +105
Operating Temperature Range
0.47 F 15000 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
2 I 0.01CV 3 A( )20
After application of rated voltage for 2 minutes: I 0.01CV or 3 A(Whichever is greater)20
Leakage Current C: ( F) C: Nominal Capacitance in F;
V: (V) V: Rated Working Voltage in V
(V) Rated Working Voltage 6.3 10 16 25 35 50 63 100
(tan )
tan (MAX) (20 ,120Hz) 0.18 0.16 0.14 0.12 0.12 0.10 0.09 0.08
Dissipation Factor
1000 F 1000 F 0.02
When capacitance is over 1000 F, tan shall be added 0.02 with increase of every 1000 F
(V)
6.3 10 16 25~100
Rated Working Voltage
Temperature Stability (Z-25 /z+20 ) 4 3 2 2
Impedance Ratio(120Hz) (Z-55 /z+20 ) 8 6 4 3
+105 5000 :
After applying rated voltage for 5000 hours at +105 , Capacitors meet the characteristics
requirements measured at +20 listed below;
25% (hrs)Life Time
Load Life Capacitance Change Within 25% of the initial measured value Case Dia 6.3-100WV 160-250WV
D 6.3 3000
Leakage current Less than the initial specified value
D 10 4000 2000
200%
Tan Less than 200% the initial specified value D 12.5 5000 2000
+105 2000
After application of rated working voltage and maximum permissible ripple current specified at +105
Shelf Life for 2000 hours , Capacitors meet the characteristics requirements measured at +20 listed below:
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz) 50(60) 100(120) 1K 10K 100K
Cap( F)
0.47~4.7 0.35 0.42 0.60 0.80 1.00
10~33 0.45 0.55 0.75 0.90 1.00
47~330 0.60 0.70 0.85 0.95 1.00
470~1000 0.65 0.75 0.90 0.98 1.00
2200~15000 0.75 0.80 0.95 1.00 1.00
60
ALUMINUM ELECTROLYTIC CAPACITOR(CD289H LF)
CASE SIZE TABLE
0.5 1.0
D 5 6.3 8 10 12.5 16 18
F 0.5 2.0 2.5 3.5 5 7.5
d 0.1 0.5 0.6 0.8
L 16 1.5 L 16 2.0
LF
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(V) 6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE)
Cap
( F) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3)
33(330) 5X11 150 0.90 5X11 150 0.90
47(470) 5X11 150 0.90 5X11 150 0.90 5X11 250 0.40
100(101) 5X11 150 0.90 5X11 150 0.90 6.3X11 250 0.40 6.3X11 250 0.40 8X12 400 0.25
220(221) 6.3X11 250 0.40 6.3X11 250 0.40 8X12 400 0.25 8X12 400 0.25 10X12 580 0.16
330(331) 6.3X11 250 0.40 8X12 400 0.25 8X12 400 0.25 10X12 580 0.16 10X16 770 0.12
470(471) 8X12 400 0.25 8X12 400 0.25 10X12 580 0.16 10X16 770 0.12 10X20 1050 0.078
1000(102) 10X12 580 0.16 10X16 770 0.12 10X20 1050 0.078 12.5X20 1300 0.062 12.5X25 1650 0.048
2200(222) 12.5X20 1300 0.062 12.5X20 1300 0.062 12.5X25 1650 0.048 16X25 1850 0.034 16X30 2000 0.029
3300(332) 12.5X20 1300 0.062 12.5X25 1650 0.048 16X25 1850 0.034 16X30 2000 0.029 18X35 2200 0.025
4700(472) 16X25 1850 0.034 16X25 1850 0.034 16X30 2000 0.029 18X35 2200 0.025
6800(682) 16X25 1850 0.034 16X30 2000 0.029 18X35 2200 0.025
10000(103) 16X30 2000 0.029 18X35 2200 0.025
15000(153) 18X35 2200 0.025
WV(V) 50(LF) 63(LG) 100(MA)
Cap( F) (1) (2) (3) (1) (2) (3) (1) (2) (3)
0.47(R47) 5X11 17 5.500 5X11 15 6.000
1(1R0) 5X11 30 4.000 5X11 20 4.500
2.2(2R2) 5X11 43 2.500 5X11 30 3.000
3.3(3R3) 5X11 53 2.200 5X11 40 2.700
4.7(4R7) 5X11 88 1.900 5X11 65 2.500
10(100) 5X11 100 1.500 5X11 87 2.300 6.3X11 140 1.200
22(220) 5X11 150 0.900 6.3X11 140 1.300 8X12 160 0.630
33(330) 6.3X11 250 0.400 6.3X11 140 1.200 10X12 230 0.430
47(470) 6.3X11 250 0.400 8X12 210 0.630 10X16 290 0.310
100(101) 8X12 400 0.250 10X12 300 0.430 12.5X20 430 0.160
220(221) 10X16 770 0.120 10X20 520 0.210 16X25 900 0.073
330(331) 10X20 1050 0.078 12.5X20 660 0.160 16X25 900 0.073
470(471) 12.5X20 1300 0.062 12.5X25 750 0.120
1000(102) 16X25 1850 0.034 16X30 1390 0.054
2200(222) 18X35 2200 0.025
100KHz Impedance ( at +20 ,100KHz)
Max allowable ripple current (mA r.m.s./105 ,100KHz)
Case Size D L(mm)
61
WV(V) 160(MB) 200(MC) 250(MD)
Cap(uF) (1) (2) (3) (1) (2) (3) (1) (2) (3)
22(220) 10X20 350 1.00 10X20 350 1.0 10X20 300 1.4
33(330) 12.5X20 450 0.70 12.5X25 550 0.55 12.5X25 450 0.70
47(470) 12.5X25 600 0.45 12.5X25 600 0.44 16X25 850 0.31
68(680) 12.5X25 600 0.45 16X25 950 0.24 16X30 1050 0.22
100(101) 16X25 950 0.24 16X30 1200 0.17 18X35 1200 0.18
150(151) 16X30 1200 0.17 18X35 1280 0.16
220(221) 18X35 1400 0.14 18X35 1400 0.14
100KHz Impedance ( at +20 ,100KHz)
Max allowable ripple current (mA r.m.s./105 ,100KHz)
Case Size D L(mm)
62
