Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] LM Series](/pics/5c2dcd100aabe.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] LM Series documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR(CD289 LM)
LM FEATURE
: 105 4000 Life time:105 4000 hours
Low impedance
For switching power supplies and other industrial
electronic products applications
SPECIFICATIONS
Item Performance Characteristics
Rated Voltage Range 6.3V.DC 100V.DC 160V.DC 450V.DC
-55 ~+105 -25 ~+105
Operating Temperature Range
0.47 F 15000 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
(V)
Rated working voltage 6.3 100 160 450
2
2 I 0.01CV 3 A I 0.03CV20
( )20 After application of rated After application of rated
Leakage Current Leakage Current voltage for 2 minute: I 0.01CV or 3 A voltage for 2 minutes: I
(Whichever is greater)20 0.03CV
C: ( F); V: (V)
Nominal Capacitance in F; Rated Working Voltage in V
(V)
Rated working voltage 6.3 10 16 25 35 50 63 100 160-450
(tan )
tan (MAX)
(20 ,120Hz) 0.18 0.16 0.14 0.12 0.12 0.10 0.09 0.08 0.10
Dissipation Factor
1000 F 1000 F 0.02
When capacitance is over 1000 F, tan shall be added0.02 with increase of every 1000 F
(V)
6.3-16 25-100 160-250 350-450
Rated working voltage
Z-25 /Z+20 __ __ 3 6
Temperature Stability (120Hz)
Impedance
Ratio Z-55 /Z+20 __ __ 4 8
+105 2000 :
After application of rated working voltage and maximum
permissible ripple current specified of +105 for 2000hours, Capacitors
meet the characteristics requirement measured at +20 listed below:
20% (hrs)
Load Life Capacitance Change Within 20% of the initial measured value Case Dia Life Time
D 8 2000
Leakage Current Less than the initial specified value
D 10 3000
200%
tan Less than 200%of the initial specified value D 12.5 5000
+105 1000
After Leaving capacitor under no load at +105 for 1000 hours, Capacitors meet the
Shelf Life
characteristics listed above.
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Cap( F) WV(V) 50(60) 100(120) 1K 10K
0.47~4.7 0.35 0.42 0.60 1.00
6.8~33 0.45 0.55 0.75 1.00
47~330 0.60 0.70 0.85 1.00
470~1000 0.65 0.75 0.90 1.00
1200~15000 0.75 0.80 0.95 1.00
69
CASE SIZE TABLE
0.5 1.0
D 5 6.3 8 10 12.5 16 18
F 0.5 2.0 2.5 2.5 5 7.5
d 0.1 0.5 0.6 0.8
L 16 1.5 L 16;2.0
LM
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV
6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE) 50(LF) 63(LG) 100(MA)
(V)
Cap (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3)
( F)
0.47
5 11 11 23.00 5 11 8 43.00
(R47)
0.68
5 11 14 16.00 5 11 11 23.00
(R68)
1
5 11 18 11.00 5 11 13 17.00
(1R0)
1.5
5 11 22 7.500 5 11 17 10.00
(1R5)
2.2
5 11 27 5.000 5 11 21 6.600
(2R2)
3.3
5 11 33 3.300 5 11 27 4.100
(3R3)
4.7
5 11 40 2.200 6.3 11 34 2.800
(4R7)
6.8
5 11 45 1.800 6.3 11 41 1.900
(6R8)
10
5 11 57 1.400 5 11 67 1.060 6.3 11 52 1.200
(100)
15
5 11 72 0.930 6.3 11 92 0.730 8 12 65 0.810
(150)
22
5 11 85 0.750 6.3 11 100 0.650 6.3 11 110 0.520 8 12 122 0.550
(220)
33
5 11 88 0.800 6.3 11 125 0.490 6.3 11 135 0.430 8 12 170 0.350 10 12 166 0.420
(330)
47
5 11 92 0.800 6.3 11 125 0.550 6.3 11 160 0.340 8 12 195 0.300 8 12 215 0.250 10 20 252 0.280
(470)
68
(680) 5 11 97 0.800 6.3 11 135 0.500 6.3 11 160 0.360 8 12 230 0.240 8 12 225 0.200 10 12 310 0.190 10 25 326 0.210
100
(101) 5 11 99 0.850 6.3 11 135 0.550 6.3 11 175 0.350 8 12 245 0.240 8 12 305 0.160 10 16 385 0.160 10 20 495 0.120 10 30 438 0.150
120
(121) 5 11 115 0.650 6.3 11 160 0.440 6.3 11 195 0.290 8 12 275 0.200 10 12 375 0.150 10 16 435 0.130 10 20 555 0.100 12.5 25 519 0.13
150
(151) 6.3 11 155 0.490 6.3 11 185 0.350 8 12 260 0.230 8 12 320 0.160 10 12 435 0.120 10 20 570 0.100 10 25 665 0.090 12.5 25 553 0.110
180
(181) 6.3 11 175 0.390 6.3 11 205 0.290 8 12 285 0.200 10 12 395 0.150 10 16 500 0.110 10 20 635 0.085 10 30 790 0.075 16 20 706 0.110
220
(221) 6.3 11 205 0.300 8 12 270 0.240 8 12 335 0.160 10 12 435 0.130 10 16 560 0.090 10 25 760 0.075 12.5 20 835 0.065 16 25 854 0.093
270
(271) 8 12 275 0.240 8 12 300 0.200 10 12 430 0.140 10 16 525 0.110 10 20 735 0.070 10 30 900 0.065 12.5 25 1000 0.055 18 20 918 0.080
330
(331) 8 12 310 0.200 8 12 350 0.160 10 12 480 0.120 10 16 575 0.095 10 20 810 0.060 10 30 995 0.055 12.5 25 1090 0.049 16 30 1160 0.062
390
(391) 8 12 345 0.170 10 12 430 0.150 10 16 570 0.100 10 20 770 0.070 10 25 955 0.055 12.5 25 1120 0.048 16 20 1170 0.047 18 30 1210 0.060
470
(471) 10 12 455 0.140 10 12 475 0.130 10 16 615 0.090 10 20 810 0.065 10 30 1130 0.046 12.5 25 1190 0.044 16 25 1350 0.042 18 35 1110 0.056
560
(561) 10 12 485 0.130 10 16 565 0.110 10 20 770 0.075 10 25 990 0.055 12.5 20 1160 0.041 16 20 1260 0.044 18 20 1400 0.039 18 35 1680 0.041
680
(681) 10 16 580 0.110 10 16 635 0.090 10 20 845 0.065 10 30 1180 0.046 12.5 25 1370 0.036 16 20 1350 0.040 16 30 1700 0.032 18 40 1910 0.036
820
(821) 10 16 635 0.095 10 20 835 0.070 10 25 1030 0.055 12.5 20 1210 0.041 12.5 25 1490 0.032 18 20 1530 0.036 18 30 1780 0.032
1000
(102) 10 20 820 0.075 10 20 915 0.060 10 30 1210 0.047 12.5 25 1430 0.036 16 20 1530 0.034 16 30 1830 0.030 18 35 1970 0.029
1200
(122) 10 20 895 0.065 10 25 1120 0.050 12.5 20 1250 0.041 12.5 25 1550 0.032 16 25 1740 0.031 18 30 1880 0.027 18 40 2210 0.025
1500
(152) 10 25 1090 0.055 10 30 1290 0.045 12.5 25 1490 0.036 16 20 1590 0.034 18 20 1840 0.028 18 30 1990 0.029
1800
(182) 10 30 1230 0.050 12.5 20 1320 0.039 16 20 1530 0.037 16 25 1780 0.031 16 30 2220 0.022 18 35 2210 0.025
2200
(222) 10 30 1320 0.043 12.5 25 1530 0.034 16 20 1620 0.033 18 20 1840 0.028 18 30 2240 0.023 18 40 2300 0.024
2700
(272) 12.5 25 1430 0.038 16 20 1560 0.035 16 25 1800 0.030 16 30 2220 0.022 18 35 2420 0.021
3300
(332) 12.5 25 1530 0.034 16 20 1660 0.031 18 20 1880 0.027 18 30 2240 0.023 18 40 2730 0.017
3900
(392) 16 20 1540 0.036 18 20 1840 0.028 16 30 2220 0.022 18 35 2420 0.021
4700
(472) 18 20 1720 0.032 16 30 2170 0.023 18 30 2240 0.023 18 40 2660 0.018
5600
(562) 18 20 1780 0.030 18 25 2100 0.024 18 35 2350 0.022
6800
(682) 16 30 2130 0.024 18 30 2280 0.022 18 35 2610 0.018
8200
(822) 18 30 2150 0.025 18 35 2420 0.021 18 40 2730 0.017
10000
(103) 18 30 2240 0.023 18 40 2730 0.017
12000
(123) 18 35 2530 0.019
15000
(153) 18 40 2660 0.018
70
ALUMINUM ELECTROLYTIC CAPACITOR(CD289 LM)
LM
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV 160(MB) 200(MC) 250(MD) 400(VA) 450(VB)
Cap (V)
( F) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3)
1(1R0)
2.2(2R2) 10 12 28 8.0 10 12 28 7.9
3.3(3R3) 10 16 47 6.5 10 16 48 6.2
4.7(4R7) 10 16 60 4.0 10 20 55 3.8 10 20 55 3.8
10(100) 10 16 155 2.5 10 16 155 2.5 10 20 125 2.3 12.5 20 85 2.6 12.5 20 90 2.6
22(220) 10 20 175 1.5 10 20 175 1.5 12.5 20 170 1.2 16 25 30 1.2 16 25 135 1.0
33(330) 12.5 20 265 0.71 12.5 20 245 0.71 12.5 25 170 0.70 16 30 70 0.65 16 30 170 0.62
47(470) 12.5 20 275 0.46 12.5 30 275 0.46 16 25 285 0.60 18 30 205 0.50 18 30 280 0.48
100(101) 16 25 345 0.24 16 25 345 0.25 18 30 300 0.30 18 35 275 0.34 18 40 310 0.36
220(221) 18 30 455 0.21 18 30 455 0.22 18 40 335 0.27
18 35 0.19 18 35 0.18
Max allowable ripple current (mA r.m.s./105 .100KHz)
100KHz Impedance ( at +20 .100KHz)
Case Size D L(mm)
