Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] RA Series](/pics/5c2dcd26a4f7b.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] RA Series documenatation <<
Text preview - extract from the document
RA FEATURE
: 105 10000 Life time:105 10000 hours
High ripple current, High temperature,
extreme long life specially designed for electronic ballast and energy-save lamp
SPECIFICATIONS
Item Performance Characteristics
160V.DC 450V.DC
Rated Working Voltage Range
-25 +105
Operating Temperature Range
1 F 220 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
2=0.03CV A (2 minute)
Leakage Current C: ( F) V: (V) I: ( A)
Nominal Capacitance in F; Rated Working Voltage in V; Leakage Current in A
(V) 160 200 250 350 400 450
(tan ) Rated Working Voltage
Dissipation Factor Tan (MAX)
0.15 0.15 0.15 0.15 0.15 0.15
(20 ,120Hz)
(V)
160 200 250 350 400 450
Rated Working Voltage
Temperature Stability (120Hz)
(Z-25 /Z+20 ) 3 3 3 6 6 6
Impedance Ratio
+105 8000 :
After application of rated working voltage and maximum permissible ripple current specified at +105 for
8000 hours, capacitors meet the characteristics requirements measured at +20 listed below
(hrs)
Load Life
Leakage current Less than the initial specified value Case Dia Life Time
200% 8 12 10 12 5000
Tan Less than 200% of the initial specified value
10 16 10 12 8000
20%
Capacitance Change Within 20% of the initial measured D 12.5 10000
+105 1000 ( )
After leaving capacitors under no load at +105 for 1000 hours, capacitors meet the
Shelf Life
characteristics listed above (Measurements shall be identified with the limits for load life).
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz) 50(60) 100(120) 1k 10k 100k
Coofficiont 0.25 0.50 0.80 0.90 1.00
84
ALUMINUM ELECTROLYTIC CAPACITOR(CD83 RA)
CASE SIZE TABLE
D 8 10 12.5 16 18
F 0.5 3.5 5 7.5
d 0.1 0.6 0.6 0.8
L 12 12,16,20 20,25 20,25 20,25
RA DIMENSIONS RATED VOLTAGE AND CAPACITANCE
WV(V) 160(MB) 200(MC) 250(MD) 350(MF) 400(VA) 450(VB)
Cap(uF) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
8 12 60
1(1R0)
10 12 70
8 12 90
1.5(1R5)
10 12 100
8 12 95
1.8(1R8)
10 12 120
8 12 95
2.2(2R2)
10 12 140
10 12 150
3.3(3R3)
10 16 180
4.7(4R7) 8 12 160 10 12 150 10 16 220 10 20 220
5.6(5R6) 10 12 180 10 16 250 10 20 250
6.8(6R8) 10 12 250 10 16 280 10 16 280 10 20 280
10(100) 10 16 320 10 16 320 10 16 320 10 20 350 10 20 350 12.5 20 450
15(150) 12.5 20 550 12.5 25 600
12.5 25
22(220) 10 20 500 10 20 500 10 20 500 12.5 20 650 760 16 20 730
16 20
33(330) 10 20 650 10 20 650 12.5 20 800 16 20 900 16 20 900 16 25 980
16 25
47(470) 10 20 750 12.5 20 980 12.5 20 980 16 20 1080 1180 18 25 1200
18 20
12.5 25
68(680) 12.5 20 1180 1300 16 20 1300 18 25 1470 18 25 1470
16 20
82(820) 16 20 1380 16 20 1380 18 25 1530
12.5 25
100(101) 1420 16 20 1420 16 25 1530
16 20
150(151) 16 25 1890 16 25 1890 18 25 1940
220(221) 18 25 2370
Max allowable ripple current (mA r.m.s./105 ,100KHz)
Case Size D L(mm)
85
