Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] RF Series](/pics/5c2dcd290fcc5.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] RF Series documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR(CD83F RF)
RF FEATURE
: 105 5000 Life time:105 5000 hours
Ideally suited for high stability circuits
SPECIFICATIONS
Item Performance Characteristics
Rated Voltage Range 6.3V.DC 50V.DC 160V.DC 450V.DC
-40 ~+105 -25 ~+105
Operating Temperature Range
Nominal Capacitance Range 0.47 F 15000 F 0.47 F 220 F
Capacitance Tolerance 20%(M,+20 ,120Hz)
(V)
Rated working 6.3 50 160 450
voltage
2 I 0.01CV 3 A 2
I 0.03CV A20
( )20 After application of rated
Leakage Current After application of rated
Leakage Current voltage for 2 minutes:I 0.01CV or 3 A voltage for 2 minutes: I
(Whichever is greater)20 0.03CV A20
C: ( F); V: (V)
Nominal Capacitance in F; Rated Working Voltage in V
(V)
Rated working voltage 6.3 10 16 25 35 50 160~450
(tan )
tan (MAX)
0.26 0.22 0.18 0.16 0.14 0.12 0.15
Dissipation Factor (20 ,120Hz)
1000 F 1000 F 0.02
When capacitance is over 1000 F, tan shall be added0.02 with increase of every 1000 F
(V)
Rated working voltage 6.3 10 16 25 35 50 160 200 250 350~450
-25 /Z
(120Hz) 4 3 2 3 4
Temperature Stability +20
Impedance
-40 /Z
Ratio 8 6 4 3
+20
+105 5000 :
After application of rated working voltage and maximum
permissible ripple current specified of +105 for 5000hours Capacitors
meet the characteristics requirement measured at +20 listed :
20% (hrs)
Capacitance Change Within 20% of the initial measured value Case Dia Life Time
Load Life
D 8 3000
Leakage Current Less than the initial specified value
200% D 10 5000
tan Less than 200%of the initial specified value
+105 1000
After Leaving capacitor under no load at +105 for 1000 hours, Capacitors meet the
Shelf Life characteristics listed above.
79
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz)
50(60) 100(120) 1K 10K 100K
WV(V)
6.3~100 0.20 0.40 0.70 0.80 1.00
160~450 0.25 0.50 0.80 0.90 1.00
CASE SIZE TABLE
0.5 1.0
D 5 6.3 8 10 12.5 16 18
F 0.5 2.0 2.5 3.5 5 7.5
d 0.1 0.5 0.6 0.8
L 16 1.5 L 16 2.0
80
ALUMINUM ELECTROLYTIC CAPACITOR(CD83F RF)
RF
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(V) 6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE) 50(LF)
Cap(uF) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
0.47(R47) 5 11 7
0.68(R68) 5 11 9
1(1R0) 5 11 12
1.5(1R5) 5 11 15
2.2(2R2) 5 11 18
3.3(3R3) 5 11 22
4.7(4R7) 5 11 27
6.8(6R8) 5 11 33
10(100) 5 11 39
15(150) 5 11 46
22(220) 5 11 47 6.3 11 65
33(330) 5 11 49 6.3 11 64 6.3 11 80
47(470) 5 11 60 6.3 11 64 6.3 11 82 8 12 105
68(680) 6.3 11 81 6.3 11 84 8 12 105 8 12 190
100(101) 5 11 64 6.3 11 82 6.3 11 100 8 12 110 8 12 200 10 16 250
150(151) 6.3 11 91 6.3 11 105 8 12 135 8 12 205 10 12 265 10 20 400
220(221) 6.3 11 120 8 12 140 8 12 215 10 12 270 10 16 350 10 25 530
330(331) 8 12 160 8 12 225 10 12 300 10 16 355 10 20 495 12.5 20 680
470(471) 10 12 280 10 12 295 10 16 380 10 20 495 12.5 20 670 12.5 25 815
680(681) 10 16 355 10 16 395 10 20 515 12.5 20 700 12.5 25 820 16 20 1110
1000(102) 10 16 495 10 20 555 12.5 20 720 12.5 25 850 16 20 1080 16 30 1520
1500(152) 10 20 650 12.5 20 770 12.5 25 885 16 20 1130 18 20 1320 18 30 1710
2200(222) 12.5 20 780 12.5 25 905 16 20 1140 18 20 1320 18 30 1650 18 40 2080
3300(332) 12.5 25 915 16 20 1180 18 20 1330 18 30 1640 18 40 2080
4700(472) 16 20 1230 18 20 1580 18 30 1640 18 40 2060
6800(682) 18 20 1550 18 30 1680 18 35 1950
10000(103) 18 30 1640 18 40 2080
15000(153) 18 40 2060
WV(V) 160(MB) 200(MC) 250(MD) 350(MR) 400(VA) 450(VB)
Cap(uF) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
1.0(1R0) 8 12 80 8 12 90
1.8(1R8) 10 12 100 10 12 110
2.2(2R2) 10 16 160 10 16 160
3.3(3R3) 10 16 180 10 16 180 10 16 180
4.7(4R7) 10 16 220 10 16 220 10 20 250
6.8(6R8) 10 16 220 10 16 220 10 20 280
10(100) 10 12 210 10 16 300 10 16 300 10 20 280 10 20 280 12.5 20 310
22(220) 10 16 300 10 16 360 10 20 500 12.5 20 350 12.5 25 430 12.5 25 450
33(330) 10 20 360 10 20 500 12.5 20 600 12.5 25 430 16 25 640 16 30 660
47(470) 12.5 20 500 12.5 20 660 12.5 25 720 16 25 660 16 30 750 18 30 780
68(680) 12.5 25 660 12.5 25 760 16 25 920 18 30 820
100(101) 16 25 750 16 25 1120
220(221) 18 30 1110 18 35 1400
Max allowable ripple current (mA r.m.s./105 ,100KHz)
Case Size D L(mm)
