Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] RG Series](/pics/5c2dcd2bbab36.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] RG Series documenatation <<
Text preview - extract from the document
RG FEATURE
: 105 8000 Life time:105 8000 hours
High ripple current long life
Ideally suited for high stability circuits
SPECIFICATIONS
Item Performance Characteristics
160V.DC 450V.DC
Rated Working Voltage Range
-40 +105
Operating Temperature Range
6.8 F 220 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
(V) 160 450
Rated working voltage
2
I 0.03CV A20
Leakage Current
After application of rated
Leakage Current voltage for 2 minutes: I
0.03CV A20
C: ( F) C: Nominal Capacitance in F;
V: (V) V: Rated Working Voltage in V
(V) 160~450
(tan ) Rated Working Voltage
Dissipation Factor Tan (MAX)
0.15
(20 ,120Hz)
(V)
160~250 350-450
Rated Working Voltage
Temperature Stability (120Hz)
(Z-25 /Z+20 ) 3 6
Impedance Ratio
+105 8000 :
After application of rated working voltage and maximum permissible ripple current specified at +105 for
8000 hours, capacitors meet the characteristics requirements measured at +20 listed below
25%
Load Life
Capacitance Change Within 25% of the initial measured value
Leakage current Less than the initial specified value
200% 0.4 ( )
Tan Less than 200% of the initial specified value or 0.4
+105 1000
After leaving capacitors under no load at +105 for 1000 hours, capacitors meet the
Shelf Life
characteristics listed above
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz) 50(60) 100(120) 1k 10k 100k
Coofficiont 0.25 0.50 0.80 0.90 1.00
82
ALUMINUM ELECTROLYTIC CAPACITOR(CD83 RG)
CASE SIZE TABLE
0.5 1.0
D 6.3 8 10 13 16 18
F 0.5 2.5 3.5 5.0 7.5
d 0.1 0.5 0.6 0.8
L 16 1.5 L 16 2.0
RG
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(V) 160(MB) 200(MC) 250(MD) 350(MF) 400(VA) 450(VB)
Cap(uF) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
6.8(6R8) 10 16 220 10 16 220 10 20 150
10(100) 10 16 250 10 16 250 10 20 280 10 20 280 10 20 280 12.5 20 320
12.5 25 16 25
22(220) 10 20 500 10 20 500 12.5 20 600 12.5 20 350 430 560
16 20 18 20
16 25 16 30
33(330) 10 20 500 12.5 20 600 12.5 20 600 16 20 500 640 700
18 20 18 25
12.5 25 16 25 16 30
47(470) 12.5 20 660 12.5 20 660 720 660 840 18 30 880
16 20 18 20 18 25
12.5 25 12.5 25 16 25 16 30
68(680) 760 760 920 850 18 30 1000
16 20 16 20 18 20 18 25
16 25 16 25 16 30
100(101) 1120 1120 1200
18 20 18 20 18 25
16 30 16 30
150(151) 1360 1360 18 30 1500
18 25 18 25
16 30
220(221) 1400 18 30 1700
18 25
Max allowable ripple current (mA r.m.s./105 ,100KHz)
Case Size D L(mm)
