Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] SE Series](/pics/5c2dcd3bd4d1d.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] SE Series documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR(CD287 SE)
SE FEATURE
: 105 1000 Life time:105 1000 hours
7mm
Low impedance series with 7 mm height
For switching power supplies and other industrial
electronic products applications
SPECIFICATIONS
Item Performance Characteristics
6.3V.DC 50V.DC
Rated Voltage Range
-55 +105
Operating Temperature Range
10 F 220 F
Nominal Capacitance Range
20%(M,+20 ,120Hz)
Capacitance Tolerance
2 I 0.01CV 3 A
( )20 After application of rated
Leakage Current voltage for 2 minute: I 0.01CV or 3 A
(Whichever is greater)20
Leakage Current
C: F; V: V
Nominal Capacitance in F; Rated Working Voltage inV
(V)
(tan ) Rated working voltage 6.3 10 16 25 35 50
Dissipation Factor tan (MAX)
0.18 0.16 0.14 0.12 0.12 0.10
(20 ,120Hz)
(V)
6.3 10 16 25 35 50
Rated working voltage
Temperature Stability Z-25 /Z+20 2 2 2 2 2 2
(120Hz)
Impedance Ratio
Z-55 /Z+20 3 3 3 3 3 3
+105 1000 :
After appliying rated voltage for 1000hours at +105 Capacitors
meet the characteristics requirement measured at +20 listed below:
25%
Capacitance Change Within 25% of the initial measured value
Load Life
Leakage Current Less than the initial specified value
200%
tan Less than 200% the initial specified value
+105 1000
After Leaving capacitor under no load at +105 for 1000 hours, Capacitors meet the
Shelf Life
characteristics listed above.
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz) 50(60) 100(120) 1K 10K 100K
10~33 0.35 0.50 0.73 0.92 1.00
Coefficient 47~68 0.40 0.55 0.77 0.94 1.00
100~220 0.45 0.60 0.80 0.96 1.00
67
CASE SIZE TABLE
D 4 5 6.3 8
F 0.5 1.5 2.0 2.5 3.5
d 0.1 0.45 0.5
SE
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(V) 6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE) 50(LF)
Cap( F) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3)
10(100) 4X7 130 0.96 4X7 130 0.96 5X7 210 0.50
15(150) 4X7 130 0.60 5X7 150 0.60 6.3X7 220 0.42
22(220) 4X7 110 0.98 4X7 130 0.85 5X7 210 0.46 6.3X7 210 0.44 6.3X7 300 0.26
33(330) 4X7 130 0.85 5X7 130 0.85 5X7 210 0.45 6.3X7 250 0.50 6.3X7 250 0.30 8X7 380 0.17
47(470) 5X7 150 0.60 5X7 210 0.44 6.3X7 220 0.42 6.3X7 250 0.30 8X7 320 0.18
68(680) 5X7 210 0.43 6.3X7 220 0.42 6.3X7 300 0.24 8X7 300 0.24
100(101) 6.3X7 250 0.30 6.3X7 250 0.30 8X7 320 0.18 8X7 380 0.15
150(151) 6.3X7 300 0.23 8X7 380 0.15
220(221) 8X7 380 0.15 8X7 405 0.13
100KHz Impedance ( at +20 .100KHz)
Max allowable ripple current (mA r.m.s./105 .100KHz)
Case Size D L(mm)
