Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] WF Series](/pics/5c2dcd43afb54.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] WF Series documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR(CD110H WF)
WF FEATURE
: 85 5000 Life time:85 5000 hours
High performance
For general consumer and industrial electronic
products application
SPECIFICATIONS
Item Performance Characteristics
Rated Voltage Range 6.3V.DC 100V.DC 160V.DC 450V.DC
-40 ~+85 -25 +85
Operating Temperature Range
0.1 F 22000 F 1 F 220 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
V
Rated working voltage 6.3 100 160 450
2
2 I 0.01CV 3 A I 0.03CV A( )
( )20 After application of rated 20 After application of
Leakage Current Leakage Current voltage for 2 minutes:I 0.01CV or 3 A rated voltage for 2 minutes:
(Whichever is greater)20 I 0.03CV A
(Whichever is greater)20
C: ( F); V: (V)
Nominal Capacitance in F; Rated working Voltage in V
(V)
Rated working voltage 6.3 10 16 25 35 50 63 100 160~450
(tan )
tan (MAX) 0.24 0.20 0.16 0.14 0.12 0.10 0.09 0.08 0.15
Dissipation Factor (20 ,120Hz)
1000 F 1000 F 0.02
When capacitance is over 1000 F, tan shall be added0.02 with increase of every 1000 F
(V)
Rated working voltage 6.3 10 16 25 35 50 63 100 160~250 350~450
Z-25 /Z 3 2 3 6
4
Temperature Stability (120Hz) +20
Impedance
Ratio Z-40 /Z
+20 8 6 4 3
+85 5000 :
After application of rated working voltage and maximum permissible ripple current
specified of +85 for 5000hours at +85 Capacitors meet the characteristics
requirement measured at +20 listed below:
20%
Load Life Capacitance Change Within 20% of the initial measured value
Leakage Current Less than the initial specified value
200%
tan Less than 200% of the initial specified value
+85 1000
After Leaving capacitor under no load at +85 for 1000 hours, Capacitors meet the
Shelf Life
characteristics listed above.
45
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz)
50(60) 100(120) 1K 10K
Cap ( F)
0.1~1.5 0.50 1.00 1.20 1.50
2.2~6.8 0.65 1.00 1.30 1.50
10~68 0.80 1.00 1.15 1.20
100~1000 0.80 1.00 1.10 1.15
1500~22000 0.80 1.00 1.10 1.15
CASE SIZE TABLE
0.5 1.0
D 5 6.3 8 10 12.5 16 18
F 0.5 2.0 2.5 3.5 5 7.5
d 0.1 0.5 0.6 0.8
L 16;1.5 L 16;2.0
WF
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(V) 6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE) 50(LF) 63(LG) 100(MA)
Cap(uF) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
0.47(R47) 5X11 7 5X11 10
0.68(R68) 5X11 10 5X11 12
1(1R0) 5X11 12 5X11 15
1.5(1R5) 5X11 16 5X11 17
2.2(2R2) 5X11 18 5X11 22
3.3(3R3) 5X11 25 5X11 29
4.7(4R7) 5X11 24 5X11 27 5X11 30 5X11 34 5X11 37
6.8(6R8) 5X11 39 5X11 31 5X11 38 5X11 45 6.3X11 46
10(100) 5X11 35 5X11 39 5X11 44 5X11 50 5X11 55 6.3X11 65
15(150) 5X11 41 5X11 47 5X11 51 5X11 52 6.3X11 60 8X12 75
22(220) 5X11 34 5X11 45 5X11 54 5X11 58 5X11 65 5X11 75 6.3X11 90 8X12 115
33(330) 5X11 55 5X11 58 5X11 65 5X11 69 5X11 85 6.3X11 105 6.3X11 110 10X12 160
47(470) 5X11 65 5X11 70 5X11 80 5X11 84 6.3X11 115 6.3X11 125 8X12 155 10X16 210
68(680) 5X11 74 5X11 80 6.3X11 100 6.3X11 107 6.3X11 130 8X12 153 8X12 170 10X20 230
100(101) 5X11 100 5X11 105 6.3X11 130 6.3X11 140 8X12 190 8X12 210 10X12 260 12.5X20 385
150(151) 6.3X11 123 6.3X11 134 6.3X11 169 8X12 184 8X12 230 10X16 276 10X20 320 12.5X25 450
220(221) 6.3X11 160 6.3X11 175 8X12 220 8X12 240 10X12 325 10X16 400 10X20 465 16X25 590
330(331) 6.3X11 210 8X12 250 8X12 270 10X12 355 10X16 440 10X20 535 12.5X20 650 16X25 720
470(471) 8X12 285 8X12 295 10X12 395 10X16 470 10X20 580 12.5X20 730 12.5X25 800 16X30 875
680(681) 8X12 353 10X16 415 10X16 492 10X20 569 12.5X20 660 12.5X25 815 16X25 923 18X35 1120
1000(102) 10X12 460 10X16 540 10X20 700 12.5X20 855 12.5X25 995 16X25 1110 16X30 1200 18X40 1320
1500(152) 10X20 596 10X20 700 12.5X20 807 12.5X25 946 16X25 1053 16X30 1230 18X30 1560
2200(222) 12.5X20 925 12.5X20 1000 12.5X25 1150 16X25 1230 16X30 1450 18X35 1530 18X40 1840
3300(332) 12.5X20 1100 12.5X25 1220 16X25 1300 16X30 1450 18X35 1660
4700(472) 16X25 1320 16X25 1410 16X30 1560 18X35 1660 18X40 2030
6800(682) 16X25 1480 16X30 1610 18X35 1750
10000(103) 16X30 1820 18X35 1950 18X40 2150
46
ALUMINUM ELECTROLYTIC CAPACITOR(CD110H WF)
WV(V) 160(MB) 200(MC) 250(MD) 350(MF) 400(VA) 450(VB)
Cap(uF) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
1(1R0) 6.3X11 17 6.3X11 17 6.3X11 17 10X12 17 10X12 16 10X12 18
1.5(1R5) 6.3X11 20 6.3X11 20 6.3X11 24 10X12 24 10X12 23 10X12 21
2.2(2R2) 6.3X11 25 6.3X11 25 8X12 29 10X16 31 10X12 27 10X12 29
3.3(3R3) 8X12 36 8X12 36 8X12 42 10X16 38 10X16 36 10X16 41
4.7(4R7) 8X12 43 8X12 50 10X12 50 10X20 49 10X20 43 10X20 49
6.8(6R8) 10X12 52 10X12 32 10X16 69 10X20 73 12.5X20 60 12.5X20 60
10(100) 10X12 70 10X16 80 10X20 88 12.5X20 82 12.5X20 72 12.5X20 75
15(150) 10X20 100 10X20 110 10X20 120 12.5X20 120 12.5X25 90 12.5X25 95
22(220) 10X20 130 10X20 140 12.5X20 155 12.5X25 130 16X25 110 16X25 115
33(330) 12.5X20 180 12.5X20 190 12.5X25 190 16X25 160 16X30 140 18X30 145
47(470) 12.5X25 220 12.5X25 220 16X25 230 18X25 200 18X30 170 18X35 170
68(680) 16X25 280 16X25 270 16X30 320 18X30 270 18X35 210
100(101) 16X25 330 16X25 335 18X30 340 18X40 310 18X40 300
150(151) 16X30 420 18X30 420
220(221) 18X30 500 18X35 515
Max allowable ripple current (mA r.m.s./85 .120Hz)
Case Size D L (mm)
47
