![LH NOVA-Fenghua [smd] MP Series](/pics/5c2dcd59ee742.gif)
>> Download LH NOVA-Fenghua [smd] MP Series documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR(CD50A MP)
MP FEATURES
: 85 (105 ) 1000 Life time:85 (105 ) 1000 hours
5mm
Non-polarity series with 5 mm height
Ideally suited for exchange polarity circuit
SPECIFICATIONS
Item Performance Characteristics
6.3V.DC 50V.DC
Rated Working Voltage Range
-40 +85 (105 )
Operating Temperature Range
0.1 F 47 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
2 I 0.03CV 5 A20 ( )
After application of rated voltage for 2minutes: I 0.03CV or 5 A(Whichever is greater)20
Leakage Current C: ( F) C: Nominal Capacitance in F;
V: (V) V: Rated Working Voltage in V
(V)
Rated Working Voltage 6.3 10 16 25 35 50
(tan )
Dissipation Factor tan (MAX)
0.24 0.20 0.16 0.16 0.14 0.14
(20 ,120Hz)
(V)
6.3 10 16 25 35 50
Rated Working Voltage
Temperature Stability (z-25 /z+20 ) 4 3 2 2 2
Impedance Ratio(120Hz) (z-40 /z+20 ) 8 6 4 4 3
+85 (105 ) 500 2
After applying rated voltage for 1000 hours at +85 (105 ), Capacitors meet the characteristics
requirements measured at +20 listed below;
25%
Capacitance Change Within 25% of the initial measured value
Load Life
Leakage current Less than the initial specified value
200%
Tan Less than 200% the initial specified value
+85 (105 ) 500
After leaving capacitors under no load at +85 (105 ) for 500 hours, capacitors meet the
Shelf Life characteristics listed above
250 30
Capacitors placed on a 250 hot plate for 30 seconds with their electrode terminais facing downward
will fulfill the following conditions after being cooled to room temperature.
Test of resistance to 10%
soldering heat C/C Within 10% of the initial value
L.C. The initial standard
Tan The initial standard
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz) 50(60) 100(120)
Cap( F) 500 1K 10K
0.1~1 0.50 1.00 1.20 1.30 1.50
2.2~4.7 0.65 1.00 1.20 1.30 1.50
10~47 0.80 1.00 1.20 1.30 1.50
29
CASE SIZE TABLE
L+0.1MAX C 0.2
CAPACITACE
RATED
VOITAGE
D+0.5MAX
A
LOT NO
16V
0.2
PE
10
E
B
A
0.3MAX W1 0.5MAX
D L C B A W1 E
4 5.5 4.3 4.3 1.8 0.5 0.8 1.0
5 5.5 5.3 5.3 2.1 0.5 0.8 1.4
6 5.5 6.6 6.6 2.5 0.5 0.8 2.0
MP
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(v) 6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE) 50(LF)
Cap( F) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2) (1) (2)
0.1(R10) 4 5.5 1.0
0.22(R22) 4 5.5 2.0
0.33(R33) 4 5.5 2.8
0.47(R47) 4 5.5 4.0
1(1R0) 4 5.5 8.4
2.2(2R2) 4 5.5 8.4 5 5.5 13
3.3(3R3) 4 5.5 10 5 5.5 17 5 5.5 17
4.7(4R7) 4 5.5 12 5 5.5 19 5 5.5 18 6.3 5.5 20
10(100) 4 5.5 17 5 5.5 25 6.3 5.5 28 6.3 5.5 29
22(220) 5 5.5 28 6.3 5.5 35 6.3 5.5 37
33(330) 6.3 5.5 37 6.3 5.5 43 6.3 5.5 49
47(470) 6.3 5.5 45
Max allowable ripple current (mA r.m.s./85 (105 ).120Hz)
