  ALUMINUM ELECTROLYTIC CAPACITORS
VZS             series Surface Mount Type()Low Impedance()
FEATURES
  Designed for surface mounting on high-density circuit board
  Emboss carrier tape packing system is available for automatic insertion


SPECIFICATIONS

        Item                                                     Performance Characteristics
Operating Temperature
       Range                                                               -40~+105
Rated Voltage Range                                                          6.3~35W.V.
 Capacitance Range                                                           1~1500F
Capacitance Tolerance
