Image preview - the first page of the document
NIC [radial thru-hole] NRSS Series


>> Download NIC [radial thru-hole] NRSS Series documenatation <<

Text preview - extract from the document
      Miniature Aluminum Electrolytic Capacitors                                                                                                                               NRSS Series
      RADIAL LEADS, POLARIZED, NEW REDUCED CASE
      SIZING (FURTHER REDUCED FROM NRSA SERIES)                                                                                 RoHS
      EXPANDED TAPING AVAILABILITY                                                                                            Compliant
                                                                                                                      includes all homogeneous materials


                NRSA                                NRSS                                                           *See Part Number System for Details
                                                                                                                        P N b S            f D il
           (today's standard)                   (reduced sizes)

      CHARACTERISTICS
                 Rated Voltage Range                                                      6.3 ~ 100Vdc
                  Capacitance Range                                                      10 ~ 10,000F
             Operating Temperature Range                                                  -40 ~ +85
