Image preview - the first page of the document



>> Download Nantung [bi-polar radial] CD71C Series documenatation <<

Text preview - extract from the document

CD71C SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 1000 hours at 85
 Bi-polarized
 7mm height, Low leakage current, High reliability
 SPECIFICATIONS
                 Item                                                                     Characteristics
Operating Temperature Range()                                                                    -40~+85
Rated Voltage Range (V)                                                                          6.3~50
Nominal capacitance range (F)                                                                    0.1~100
Capacitance Tolerance(20, 120Hz)
