Image preview - the first page of the document
Nantung [lug terminal] CD17FX Series


>> Download Nantung [lug terminal] CD17FX Series documenatation <<

Text preview - extract from the document
CD17FX SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 High stability
 Lug type
 Low leakage current reduces battery consumption
 Used for photo flash

 SPECIFICATIONS
                Item                                        Characteristics

Operating Temperature Range()                                   -20~+55

Rated Voltage                           330WV.DC                                      360WV.DC

Voltage Proof                           350SV.DC                                      390SV.DC

Nominal capacitance range (F)                                  150~1500

Capacitance Tolerance(20,120Hz)                               -10%~+20%

                                                   Capacitance:150~600F   Less than 0.1
Dissipation Factor(20,120Hz)
                                                             601~1500F     Less than 0.15

                                                       I=1XC(at 20, 5minues)Max
Leakage current
                                           I: Leakage Current (A) C: Nominal Capacitance (F)


 DIMENSIONS                        MM




                                        PAGE   1    OF 2
CD17FX SERIES
 STANDARD RATINGS
  330WV.DC(350SV.DC)
     Capacitance        D (mm)             22                 25      30     35

        ( F)               P               8.0                10.0    10.0   10.0

        150                                 -                     -    -      -

        180                                 -                     -    -      -

        200                                 -                     -    -      -

        250                                26                     -    -      -

        300                                28                     -    -      -

        350                                31                     -    -      -

        400                                35                 30       -      -

        450                                38                 32       -      -

        500              L (mm)            42                 34       -      -

        600                                48                 40      31      -

        700                                56                 44      34      -

        800                                 -                 50      38      -

        900                                 -                 54      42      -

        1000                                -                 58      44     36

        1200                                -                     -   54     43

        1300                                -                     -   58     45

        1500                                -                     -   64     51

360WV.DC(390SV.DC)

     Capacitance         D(mm)             22.0               25.0    30.0   35.0

        (F)                P               8.0                10.0    10.0   10.0

        150                                 -                     -    -      -

        180                                 -                     -    -      -

        200                                26                     -    -      -

        250                                30                     -    -      -

        300                                35                 30       -      -

        350                                40                 32       -      -

        400                                42                 35       -      -

        450                                48                 40       -      -

        500              L(mm)             56                 44      34      -

        600                                 -                 50      38      -

        700                                 -                 58      44      -

        800                                 -                     -   50     38

        900                                 -                     -   54     43

        1000                                -                     -   58     48

        1200                                -                     -   70     55

        1300                                -                     -    -     59

        1500                                -                     -    -     71


 The specific capacitance and case size are available on request.




                                                PAGE   2   OF 2
