CD50H SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 1000 hours at 105
 5mm height, Wide temperature
 SPECIFICATIONS
               Item                                                          Characteristics
Operating Temperature Range()                                                   -55+105
Rated Voltage Range (V)                                                           6.3~50
Nominal capacitance range (F)                                                     0.1~220
                                                          I.01CV or 3 whichever is greater (at 20,after 2 minutes)
Leakage Current (A)                                          C: Nominal Capacitance (F), V: Rated Voltage (v)
Capacitance Tolerance(20, 120Hz)
