Image preview - the first page of the document



>> Download Nantung [radial thru-hole] CDS(H) Series documenatation <<

Text preview - extract from the document

CDS/CDSH SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 CDS: Load life of 1000 hours at 85
 CDSH: Load life of 1000 hours at 105
 Bi-polarized, High frequency, Small loss
 Used for S correction of horizontal deflection circuits
 High and stable quality
 SPECIFICATIONS
               Item                                                               Characteristics
Operating Temperature Range()                                             -40~+85(CDSH: -40~+105)
Rated voltage Range (V)                                                               25~100
Nominal capacitance range (F)                                                          1~15
Capacitance Tolerance(20,120Hz)
