Image preview - the first page of the document



>> Download Nantung [smd] CDVB Series documenatation <<

Text preview - extract from the document

CDVB SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 For high density surface mounting, 85,2000hours guaranteed
 Carrier taping supplied
 Bi-polar Type
 Reflow soldering is available
 SPECIFICATIONS
               Item                                                         Characteristics
Temperature Range()                                                               -40~+85
Rated Voltage Range (V)                                                           6.3~50
Nominal capacitance range (F)                                                0.1~100
                                                     I0.05CV or 10 whichever is greater (at 20,after 2 minutes)
Leakage current (A)
                                                       C: Nominal Capacitance (F)       V: Rated Voltage (v)
Capacitance Tolerance(20,120Hz)
