CDVH SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 For high density surface mounting, 105,2000hours guaranteed

 Carrier taping supplied

 Reflow soldering is available
 SPECIFICATIONS
                   Item                                                                Characteristics
 Temperature Range()                                                                          -55~+105
 Rated Voltage Range (V)                                                                        4~50
 Nominal capacitance range (F)                                                                 0.1~1000
                                                              I0.01 or 3 whichever is greater (at 20, after 2 minutes)
 Leakage Current (A)
                                                                   C: Nominal Capacitance (F), V: Rated Voltage (V)
 Capacitance Tolerance(20,120Hz)
