Image preview - the first page of the document



>> Download Nantung [snap-in] CD298 Series documenatation <<

Text preview - extract from the document

CD298 SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life 5000 hours at 105
 Wide temperature, Long life
 SPECIFICATIONS
               Item                                                      Characteristics

Operating Temperature Range()                     -40~+105                                                 -25~+105

Rated Voltage Range (V)                            10~100                                                  160~450

Nominal capacitance range (F)                     560~56000                                                68~1800

Capacitance Tolerance(20,120Hz)
