Image preview - the first page of the document
Nicon LH [radial thru-hole] Series


>> Download Nicon LH [radial thru-hole] Series documenatation <<

Text preview - extract from the document
SCREW TERMINAL TYPE ALUMINIUM ELECTROLYTIC CAPACITORS

LH             Series
2000h at 105
Standard 105
Professional Power supplies & lnverters

SPECIFICATION
                     Items                                                                      Characteristics
      Operating Temperature Range()                                  40+105                                                    25+105
             Voltage rangeV                                           25+100V                                                   160450V
          Capacitance RangeF                                                                   220330000F
            Capacitance Tolerance
