                         Miniature Size 5mm Aluminum Electrolytic Capacitor
 SPKE07(105) Series
 5.0+1 mm max height
 Load life 105 hrs assured
 For the special designing requirement,please contact us.

 Specifications
              Item                                                 Performance Characteristics
  Operating Temperature Range                                               -40 to +105
      Rated Voltage Range                                                    4 to 50VDC
       Capacitance Range                                                     0.1 to 330uF
     Capacitance Tolerance
