Image preview - the first page of the document



>> Download SPK [radial thru-hole] SPKE19 Series documenatation <<

Text preview - extract from the document

                           High Ripple Current Aluminum Electrolytic Capacitor
 SPKE19 Series
 +105,High ripple current,high temperature,Standard.
 Specially designed for electronic ballast and energy-save lamp.
 For the special designing requirement,please contact us.

 Specifications
                    Item                                          Performance Characteristics
  Operating Temperature Range                                                  -40 to +105
      Rated Voltage Range                                                     200 to 450VDC
       Capacitance Range                                                         1 to 100uF
     Capacitance Tolerance
