Image preview - the first page of the document



>> Download Samcon [radial thru-hole] ELF Series documenatation <<

Text preview - extract from the document

   Samcon                               Radial Lead Aluminum Electrolytic Capacitors

                                              SERIES
                    ELF                                                                      RoHS
       105, high frequency, low impedance                                                     compliance
       5000 hours guaranteed for D10
       7000 hours guaranteed for D 13

  SPECIFICATIONS
                     Item                                                                       Characteristics
          Category Temperature Range                                  -40 ~ +105 (160V~400V.DC)                  -25 ~ +105 (450V.DC)
                Voltage Range                                                                 160V ~ 450V.DC
              Nominal Cap. Range                                                                 3.3 ~ 330 F
             Capacitance Tolerance                                                     '- 20% ~ + 20% (at 20, 120Hz)
                                                      CV         Time     1min.                            5min.
                                                        CV  1000          I = 0.1CV + 40 max               I = 0.03CV + 15 max
               Leakage Current
                                                        CV  1000          I = 0.04CV + 100 max             I = 0.02CV + 25 max
                                                       where,I: Max Leakage Current(A), C: Nominal Capacitance(F), V: Rated Voltage(V) (at 20)
           Dissipation Factor (tan)                     Rated voltage(V.DC)        160~250V       350400V 450V
             ( at 120Hz, +20 )                           tan(Max.)                    0.20            0.24       0.24
            Low Temp. Impedance                         Rated voltage(V.DC)        160~250V       350400V 450V
               Stability at 120Hz                    Z(-25)/Z(+20)                      3               5          6
                                                     Z(-40)/Z(+20)                      6               6          -
               Impedance(                                                           See case size table
                                                    After D10: 5000 hours, D 13: 7000 hours' application of DC rated working.
                                                    voltage at +105, the capacitor shall meet the following limits.
            High Temp. Load Test                    Capacitance Change ...
