Image preview - the first page of the document
Samcon [radial thru-hole] UMA Series


>> Download Samcon [radial thru-hole] UMA Series documenatation <<

Text preview - extract from the document
Samcon                                      Radial Lead Aluminum Electrolytic Capacitors

              UMA                           SERIES
                                                                                                             RoHS
          The UMA series is very small case size but possess the                                             compliance
         same high quality and performance as our standard size
         unit . They can replace more expensive dipped tantalum
         capacitors in most applications.
          Ultraminiature series with 5mm height.

 SPECIFICATIONS
                    Item                                                                           Characteristics
   Category Temperature Range                                                                      - 40 ~ +85
             Voltage Range                                                                          4 ~50 V.DC
           Nominal Cap. Range                                                                      0.1 ~ 220 F
         Capacitance Tolerance                                                   - 20% ~ + 20% (at 20, 120Hz)
                                                                   I = 0.01CV or 3(A) Whichever is greater.(after 2 minutes)
            Leakage Current
                                             where,I: Max Leakage Current(A), C: Nominal Capacitance(F), V: Rated Voltage(V) (at 20 )

         Dissipation Factor (tan)                WV          4            6.3      10        16         25        35         50
             ( at 120Hz, +20 )                  tan        0.35          0.24     0.20      0.16       0.14      0.12       0.10



          Low Temp. Impedance                          W. V .                       4       6.3         10       16          25     35        50
            Stability at 120Hz                  Z( - 25 ) / Z ( + 20 )              7        4           3        2           2      2         2
                                                Z( - 40 ) / Z ( + 20 )             15       10           8        6           4      3         3

                                              After 1000 hours' application of DC rated working voltage at 85, the capacitor shall meet the following limits:
                                              Capacitance Change            ...
