Image preview - the first page of the document
>> Download Ceramic_Capacitor documenatation <<
Text preview - extract from the document
Ceramic Type
Introduction
SAMWHA disc ceramic capacitors are designed and producted to offer the user capacitors with high
reliability and small size.
With wide selection of temperature characteristics and voltage ratings, the user can make use for in various
DISC Ceramic Capacitors
circuit application.
special specification like a Automobile, Medical, Military, Aviation should be discuss with our sales representatives
How to Order
CC C 1H 120 J 04 F K 5
Mark Product Name Mark Product Name
CC, EC Temperature Compensating Type SD AC250/400V(Testing Voltage : AC4000V)
CK, EK High Dielectric Type SC AC250(Testing Voltage : AC2500V)
CG Semiconductive Type
CE, EC Type (PPM ) CK, EK, CG, SC, SD Type
C NPO(0) T N470( 470) B Y5P( 10~ 10%)
L N80( 80) U N750( 750) R Y5R( 15~ 15%)
P N150( 150) O SL( 350~ 1000) E Y5U( 22~ 56%)
R N220( 220) F Y5V( 22~ 82%)
S N330( 330) Fz Z4V( 22~ 82%)
1A 10V 1B 12.5V 1C 16V 1E 25V 1H 50V
2A 100V 2B 125V 2E 250V 2G 400V 2H 500V
3A 1KV 3B 1.25KV 3D 2KV 3F 3.15KV 3G 4KV 3H 5KV 3J 6.3KV
4A 10KV 4B 12.5KV 4C 16KV
SAMWHA CAPACITOR Co., Ltd.
Ceramic Type
(in picofarads) The first two digits indicate significant digits. The 3rd digit indicate the number of zero following.
R denotes decimal.
Ex.)0.5 -OR5, 10 -100, 100 -101
Mark Cap. Tolerance Mark Cap. Tolerance Mark Cap. Tolerance
C 0.25 J 5% P 100% 0%
D 0.5 K 10% Z 80% 20%
F 1.0 M 20%
Code Dia( mm) Code Dia( mm) Code Dia( mm) Code Dia( mm) Code Dia( mm)
04 4.0 08 8.0 11 11.0 15 15.0 20 20.0
05 5.0 09 9.0 12 12.5 16 16.0
06 6.3 10 10.0 14 14.0 18 18.0
Packing Style Lead Variation
S Straight Type
Taping Type
F K In - Kink Type
Flat Pack
F Out - Kink Type
S Straight Long Type
W Kink Short Type
B Bulk K Kink Long Type
L Kink Short Type
N Straight Short Type
Taping Type Bulk Type
Code Lead Spacing(mm) Pitch of Component(mm) Code Lead Spacing(mm)
5 5.0 12.7 2 2.5
7 7.5 15.0 5 5.0
8 7.5 30.0 7 7.5
9 7.5 25.4 1 10.0
1 10.0 25.4
2 10.0 30.0
DISC Ceramic Capacitors
CLASS Temperature Compensating Ceramic Capacitors
Specification
Temp . Range : 25 ~ 85 (Y class)
Capacitance : Measured at 1 , 1 Vrms and 20 2
R.V T.V Capacitance Q value
50V DC 150V DC 30 and over 1000
DISC Ceramic Capacitors
500V DC 1,250V DC less then 30 400 (20 C)
1~2KV DC R.V 2 Insulation Resistance : 10,000 Min. at Rating voltage for
1 minute(500V and above : 500V)
Color Code Temp. Coefficient Tolerance
TC. Color TC. Color TC. Color Code Tol.(PPM/ ) Code Tol.(PPM/ )
NPO(C) Black N 80(L) Red N150(P) Orange G 30 L 500
N220(R) Yellow N330(S) Green N470(T) Blue H 60 M 1000
N750(U) Purple SL Omitted J 120 N 2500
K 250
Temp. Coefficient Combination of the Capacitance
Value and the TC.
TC. PPM/
Cap P350
NP0 N80 N150 N220 N330 N470 N750
~1000
C L P R S T U SL
Less then 2 CK LK PK RK SK TK UK SL
3 CJ LJ PJ RJ SJ TJ UJ SL
4 and above CH LH PH RH SH TH UJ SL
SAMWHA Standard (Cap. and Cap. Tol)
T.C Cap.Tol T.C Cap.Tol T.C Cap.Tol T.C Cap.Tol
Cap.( ) C~U, SL Cap.( ) C~U, SL Cap.( ) C~U, SL Cap.( ) C~U, SL
0.5 C, D 9 D, F 22 J, K 51 J
1 C, D 10 D, F 24 J 56 J, K
2 C, D 11 J 27 J, K 62 J
3 C, D 12 J, K 30 J 68 J, K
4 C, D 13 J 33 J, K 75 J
5 C, D 15 J, K 36 J 82 J, K
6 D, F 16 J 39 J, K 91 J
7 D, F 18 J, K 43 J 100 J, K
8 D, F 20 J 47 J, K 110 J
SAMWHA CAPACITOR Co., Ltd.
Ceramic Type
T.C Cap.Tol T.C Cap.Tol T.C Cap.Tol T.C Cap.Tol
Cap.( ) C~U, SL Cap.( ) C~U, SL Cap.( ) C~U, SL Cap.( ) C~U, SL
120 J, K 200 J 330 J, K 510 J
130 J 220 J, K 360 J 560 J, K
150 J, K 240 J 390 J, K 620 J
160 J 270 J, K 430 J 680 J, K
180 J, K 300 J 470 J, K 820 J
Lead Variation(Bulk Type)
R.V(V.DC) Unit : mm
50 1.5Max.
500 2.0Max.
Above 1KV 3.0Max.
Capacitance Value According to Type( )
Capacitance( ) Dimensions(mm)
T.C P350~ Part No.
NPO N80 N150 N220 N330 N470 N750 (How to Marking
N1000 D T F d
(C) (I) (P) (R) (S) (T) (U) order)
R.V (SL)
0.5, 1, 2, 3, 4, 1, 2, 3, 4, 5, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 0.5, 1, 2, 3, 4, 5, 4.0 3.5 5.0 0.50 CC 1H 04
5, 6, 7, 8, 9, 6, 7, 8, 9, 10, 7, 8, 9, 10, 11, 7, 8, 9, 10, 11, 7, 8, 9, 10, 11, 7, 8, 9, 10, 11, 7, 8, 9, 10, 11, 6, 7, 8, 9, 10, 11, (2.5)
10, 11, 12, 13, 11, 12, 13, 15, 12, 13, 15, 16, 12, 13, 15, 16, 12, 13, 15, 16, 12, 13, 15, 16, 12, 13, 15, 16, 12, 13, 15, 16, 18,
15, 16, 18, 20, 16, 18 18, 20 18, 20, 22, 24 18, 20 18, 20, 22, 24 18, 20, 22, 20, 22, 24, 27,
22, 24, 27 ,30 24, 27, 30, 30, 33, 36, 39,
D 5.0
33, 36 43, 47, 51, 56,
62, 68, 75, 82, 91
50V 33, 36, 39, 20, 22, 24, 22, 24, 27, 30 27, 30, 33, 36 22, 24, 27, 27, 30, 33, 39, 43, 47 100, 110, 120 5.0 3.5 5.0 0.50 CC 1H 05
DC 43, 47 27, 30 30, 33, 36, 39 36, 39 (2.5)
6.3 D
51, 56, 62, 33, 36, 39, 33, 36, 39, 39, 43, 47, 43, 47, 51, 43, 47, 51, 56 51, 56, 62, 150, 180, 200, 6.3 3.5 5.0 0.50 CC 1H 06
68, 75 43, 47 43, 47 51, 56, 62, 68 56, 62 68, 75, 82, 91 220, 240
82, 91, 100, 110, 51, 56, 62, 51, 56, 62, 75, 82, 91, 68, 75, 82, 62, 68, 75, 82, 100, 110, 120, 270, 300, 330, 8.0 3.5 5.0 0.50 CC 1H 08
120, 130, 150 68, 75, 82 68, 75, 82 100, 110, 120 91, 100 91, 100, 110, 120 150, 180, 200 360, 390, 430, 470
D 10.0
160, 180, 91, 100, 110, 91, 100, 110, 130, 150, 180, 110, 120, 150, 150, 180, 200 510, 560, 620, 10.0 3.5 5.0 0.50 CC 2H 10
200, 220, 240 120 120 200 180 680, 820
1, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 1, 2, 3, 4, 5, 6, 7, 5.0 4.0 5.0 0.50 CC 2H 05
7, 8, 9, 10, 11, 12, 13, 15 7, 8, 9, 10 8, 9, 10, 11, 12, 13,
12, 13, 15, 16, 15, 16, 18, 20, 22,
18, 20, 22, 24 24, 36, 39, 43,
47, 51, 56, 62 ,68
27, 30, 33, 2, 3, 4, 5, 6, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 2, 3, 4, 5, 6, 7, 3, 4, 5, 6, 7, 8, 9, 11, 12, 13, 15, 16, 27, 30, 33, 75, 6.3 4.0 5.0 0.50 CC 2H 05
D 5.0
36, 39, 43 7, 8, 9, 10, 11, 7, 8, 9, 10, 11, 18, 20, 22, 8, 9, 10, 11 ,12, 10, 11, 12, 13, 15, 18, 20, 22, 24, 82, 91, 100,
12, 13, 15, 16, 12, 13, 15, 16, 24, 27, 30, 33 13, 15, 16, 18, 16, 18, 20, 22, 24, 27, 30, 33, 36, 110, 120
18, 20 18, 20, 22, 20, 22, 24, 27, 27, 30, 33, 36, 39, 43, 47, 51,
500V 24, 27, 30 30, 33, 36 39, 43 56, 62, 68
DC 47, 51, 56, 22, 24, 27, 33, 36, 39, 36, 39, 43, 39, 43, 47, 47, 51, 56, 62 75, 82, 91, 130, 150, 160, 8.0 4.0 5.0 0.50 CC 6.3 D
2H 08
62, 68, 75, 82 30, 33, 36 43, 47 47, 51, 56 51, 56 100 180, 200, 220
91, 100, 110, 39, 43, 47, 51, 56, 62, 62, 68, 75, 62, 68, 75, 68, 75, 82, 91, 110, 120, 150, 240, 270, 300, 10.0 4.0 5.0 0.50 CC 2H 10
120, 130 51, 56, 62 68, 75 82, 91, 100 82, 91 100, 110 180 330, 360, 430,
390, 470, 510, D 10.0
560
150, 160, 180, 68, 75, 82, 82, 91, 100, 100, 120, 150 100, 110, 120, 120, 150, 180 200, 220, 12.5 4.0 5.0 0.50 CC 2H 12
200 91, 100 110, 120 150 240, 270, 300
DISC Ceramic Capacitors
CLASS High Dielectric Constant Ceramic Capacitors
Specification Temp. Char.
Temp . Range : 25 ~ 85 (Y class), 10 ~ 65 (Fz)
Capacitance : Measured at 1 , 1 Vrms and 20 2
R.V 50V DC 500V DC 1~2KV DC 3KV DC 4~KV DC
DISC Ceramic Capacitors
T.V R.V 3 R.V 2.5 R.V 2 R.V 1.75 R.V 1.5
Insulation Resistance : 10,000 or 200 Whichever
less at Rating Voltage for 1minute
T.C B E Fz
tan 2.5% Max. 2.5% Max. 5.0% Max.
Capacitance Value According to Type( )
T.C Capacitance( ) Dimensions(mm) Part No.
Marking
R.V Y5P(B) Y5U(E) Z4V(Fz) D T F d (How to order)
150, 180, 220, 270, 330, 390,
- 2200, 3300 4.0 3.5 5.0(2.5) 0.50 CK 1H 04
470, 560, 680
100, 120, 820, 1000, 1200, 1500 - 1000, 15000, 4700 5.0 3.5 5.0(2.5) 0.50 CK 1H 05
50V
1800, 2200 - 5600, 10000 6.3 3.5 5.0 0.50 CK 1H 06 D 5.0 6.3 D 9.0
DC
2700, 3300, 3900, 4700, 5600 - 15000, 22000, 27000 8.0 3.5 5.0 0.50 CK 1H 08
6800, 8200 - 3300, 40000 10.0 3.5 5.0 0.50 CK 1H 10 D 10.0
10000 - 47000 12.0 3.5 5.0 0.50 CK 1H 12
120, 150, 180, 220, 270, 330,
- 2200 5.0 4.0 5.0 0.50 CK 2H 05
390, 470, 560, 680
100, 820, 1000, 1200, 1500 1000 1000, 4700 6.3 4.0 5.0 0.50 CK 2H 06
500V
1800, 2200 2200 10000 8.0 4.0 5.0 0.50 CK 2H 08 D 5.0 6.3 D 9.0
DC
2700, 3900 4700 - 10.0 4.0 5.0 0.50 CK 2H 10
4700, 5600, 6800 6800 20000, 22000 12.5 4.0 5.0 0.50 CK 2H 12 D 10.0
8200, 10000 10000 - 16.0 4.0 10.0 0.60 CK 2H 16
SAMWHA CAPACITOR Co., Ltd.
Ceramic Type
DC High Voltage Ceramic Capacitors
High Voltage Ceramic Capacitors(Epoxy Coated Ceramic Capacitors)
T.C Capacitance( ) Dimensions(mm) Part No.
(How to order) Marking
R.V Y5P(B) Y5U(E) Z4V(Fz) D T F d
500V DC 10000 16.0 4.0 10.0 0.60 EK 2H 16
100, 120, 150, 180 ,220, 270,
1000 1000, 2200 6.3 5.0 5.0 0.50 EK 3A 06
330, 390, 470, 560, 680
820, 1000, 1200, 1500 4700 8.0 5.0 5.0 0.50 EK 3A 08 6.3 D
1KV 1800, 2200 2200 10000 10.0 5.0 5.0(7.5) 0.50(0.60) EK 3A 10
DC 2700, 3300 4700 12.5 5.0 5.0(7.5) 0.50(0.60) EK 3A 12
3900, 4700 14.0 5.0 7.5(10.0) 0.60 EK 3A 14
D
5600, 6800 22000 16.0 5.0 7.5(10.0) 0.60 EK 3A 16
8200, 10000 10000 18.0 5.0 7.5(10.0) 0.60 EK 3A 18
100, 120, 150, 180, 220 , 5.0 5.0 0.50
1000, 2200 6.3 EK 3D 06
270, 330, 390, 470, 560 5.0 (7.5) (0.60)
680, 820, 1000 1000 8.0 5.0 7.5(5.0) 0.60(0.50) EK 3D 08
1200, 1500 4700 10.0 5.0 10.0(7.5) 0.60 EK 3D 10 6.3 D
2KV
1800, 2200, 2700 2200 6800, 10000 12.5 5.0 10.0(7.5) 0.60 EK 3D 12
DC
3300, 3900 4700 14.0 5.0 10.0(7.5) 0.60 EK 3D 14
4700 6800,10000 16.0 5.0 10.0(7.5) 0.60 EK 3D 16 D
5600 18.0 5.0 10.0(7.5) 0.60 EK 3D 18
6800, 8200, 10000 10000 20.0 5.0 10.0(7.5) 0.60 EK 3D 20
1000 7.0 6.0 7.5(10.0) 0.60 EK 3F 07
100, 120, 150, 180, 220,
8.0 6.0 7.5(10.0) 0.60 EK 3F 08
270, 330, 390, 470, 560
680 1500 9.0 6.0 7.5(10.0) 0.60 EK 3F 09
6.3 D 9.0
3.15KV 820, 1000 2200 4700 10.0 6.0 7.5(10.0) 0.60 EK 3F 10
DC 6800 11.0 6.0 7.5(10.0) 0.60 EK 3F 11
1200, 1500 3300 12.5 6.0 7.5(10.0) 0.60 EK 3F 12
D
1800, 2200 4700 10000 14.0 6.0 7.5(10.0) 0.60 EK 3F 14
2700 16.0 6.0 7.5(10.0) 0.60 EK 3F 16
3300 18.0 6.0 7.5(10.0) 0.60 EK 3F 18
100, 120, 150, 180, 220, 330, 470 1000 1000 8.0 7.0 10.0 0.60 EK 3J 08
1500 9.0 7.0 10.0 0.60 EK 3J 09
6.3KV 1000 2200 2200, 4700 12.5 7.0 10.0 0.60 EK 3J 12 6.3 D 9.0
DC 3300 14.0 7.0 10.0 0.60 EK 3J 14
3900, 4700 15.5 7.0 10.0 0.60 EK 3J 15
D
10000 20.0 7.0 10.0 0.60 EK 3J 20
100, 120, 150, 180, 220 8.0 8.0 10.0 0.60 EK 4A 08
10KV 270 1000 10.0 8.0 10.0 0.60 EK 4A 10
DC 330, 390, 470 1000 2200 12.5 8.0 10.0 0.60 EK 4A 12
560, 680, 820, 1000 2200 4700 16.0 8.0 10.0 0.60 EK 4A 16
DISC Ceramic Capacitors
CLASS Semi-Conductor Capacitors
Specification
Temp. Range : 25 ~ 85 (Y class)
Capacitance : Measured at 1 , 0.1 Vrms and 25 2
T.C Y5P Y5R Y5V
1000 or
5 5
Rating Voltage 25V DC 50V DC I.R( ) 20
Min. Min.
Testing Voltage R.V 1.5 R.V 1.5 Whichever Iess
DISC Ceramic Capacitors
Lead Variation
T.C Y5P Y5R Y5V
R.V 25V, 50V 25V 25V, 50V
Tan 5.0% Max. 1.5% Max. 5.0% Max.
T.C Y5P Y5R Y5V
Change 22%
10% 15%
Rate 82%
Capacitance Value According to Type( )
Capacitance(pF) Dimensions(mm) Part No. Marking
T.C Y5P(B) Y5U(E) Y5V(F) D T F d (How to order)
R.V
10000 2200, 2700, 3300,
10000 4.0 3.0 5.0(2.5) 0.5 CG 1E 04
3900, 4700, 6800
D 5.0
10000, 15000 22000 5.0 3.0 5.0(2.5) 0.5 CG 1E 05
25V
22000 22000, 27000, 33000 47000, 56000, 100000 6.3 3.0 5.0 0.5 CG 1E 06
DC
6.3 D 9.0
47000 47000 8.0 3.0 5.0 0.5 CG 1E 08
56000, 68000 220000 10.0 3.0 5.0 0.5 CG 1E 10
D 10.0
100000 12.5 3.0 5.0 0.5 CG 1E 12
10000 4.0 3.0 5.0(2.5) 0.5 CG 1H 04
50V 10000 22000, 33000 5.0 3.0 5.0(2.5) 0.5 CG 1H 05 D 5.0
DC 47000, 56000 6.3 3.0 5.0 0.5 CG 1H 06
22000 68000,100000 8.0 3.0 5.0 0.5 CG 1H 08 6.3 D 9.0
SAMWHA CAPACITOR Co., Ltd.
Ceramic Type
Low Loss Ceramic Capacitors(SL & R Series)
Specification
Temp. Range : 25 ~ 85
Capacitance : Measured at 1 , 0.1 Vrms and 20 2
Testing Voltage : R.V 2
Insulation Resistance : 10,000 Min.
at 500V DC for 1 minute
T.C SL R(Y5V)
Change Rate -1000~350PPM 15%
30 and over : 1000Min.
D.F 0.2%Max.
less then 30 : 400+(20 C)Min.
Capacitance ( ) Dimensions(mm) Part No. Marking
R.V SL R(Y5R) D T F d (How to order)
10, 11, 12, 15, 18, 20, 22, 24, 27,
220, 270, 330, 390 6.3 5.0 5.0 0.50 EK 3A 06
30, 33, 39, 43, 47, 51
470 7.0 5.0 5.0 0.50 EK 3A 07
56, 62, 68, 75, 82, 91, 100 560, 680 8.0 5.0 5.0 0.50 EK 3A 08
820,1000 9.0 5.0 5.0(7.5) 0.50(0.60) EK 3A 09
110, 120, 150 1200 10.0 5.0 5.0(7.5) 0.50(0.60) EK 3A 10 6.3 D
1KV
1500 11. 0 5.0 5.0(7.5) 0.50(0.60) EK 3A 11
DC
180, 200, 220, 240, 270 12.5 5.0 5.0(7.5) 0.50(0.60) EK 3A 12
300, 330, 360 1800, 2200, 2700 14.0 5.0 10.0 0.60 EK 3A 14
3300 15.0 5.0 10.0 0.60 EK 3A 15 D
390, 430, 470, 510 16.0 5.0 10.0 0.60 EK 3A 16
3900 17.0 5.0 10.0 0.60 EK 3A 17
560, 620 4700 18.0 5.0 10.0 0.60 EK 3A 18
18, 20, 22, 24, 27, 30, 33, 36, 39, 43,47 120 6.3 5.0 5.0 0.50 EK 3D 06
220, 270 7.0 5.0 5.0 0.50 EK 3D 06
51, 56, 62, 68, 75, 82 ,91, 100 330, 390 8.0 5.0 10.0 0.60 EK 3D 07
470, 560, 680 10.0 5.0 10.0 0.60 EK 3D 08
6.3 D
820, 1000 11.0 5.0 10.0 0.60 EK 3D 11
2KV
120, 150, 180, 200 12.5 5.0 10.0 0.60 EK 3D 12
DC
220, 240 1200, 1500 14.0 5.0 10.0 0.60 EK 3D 14
1800, 2200 15.0 5.0 10.0 0.60 EK 3D 15
D
270, 300, 330, 360 16.0 5.0 10.0 0.60 EK 3D 16
2700 17.0 5.0 10.0 0.60 EK 3D 17
390, 430, 470 3300 18.0 5.0 10.0 0.60 EK 3D 18
15, 16, 18, 20, 22, 27, 30 6.3 6.0 5.0 0.50 EK 3F 06
150, 180, 220, 270 7.0 6.0 5.0 0.50 EK 3F 07
33, 36, 39, 43, 47, 51, 56 330, 390 8.0 6.0 5.0 0.50 EK 3F 08
3.15KV 62, 68, 75, 82 470, 560, 680 10.0 6.0 10.0 0.60 EK 3F 10
DC 91, 100, 110, 120, 150 820, 1000 12.5 6.0 10.0 0.60 EK 3F 12 6.3 D
180, 200 1200, 1500 14.0 6.0 10.0 0.60 EK 3F 14
220, 240 1800 16.0 6.0 10.0 0.60 EK 3F 16
270, 300, 330, 360 2200, 2700 18.0 6.0 10.0 0.60 EK 3F 18
22, 24, 27, 30, 33, 36 8.0 7.0 10.0 0.60 EK 3J 08 D
6.3KV 43, 47 220, 270, 330 10.0 7.0 10.0 0.60 EK 3J 10
DC 51, 56, 62, 68, 75 390, 470 12.5 7.0 10.0 0.60 EK 3J 12
120 560, 680 16.0 7.0 10.0 0.60 EK 3J 16
DISC Ceramic Capacitors
Safety Standard Recognized Ceramic Capacitors
Specification
Temp. Range : 25 ~ 85 (Y class), 10 ~ 65 (Fz)
Capacitance : Measured at 1 , 1 Vrms and 20 2
R.V T.V
250V AC 2,500V AC
DISC Ceramic Capacitors
400V AC 4,000V AC
T.C B E Fz
tan 2.5% Max. 2.5% Max. 5.0% Max.
How to Order(Product Identification)
SC B 2E 101 K 08 FF 7
Specification
Temp Capacitance Size D 9.0
Type D 10.0
char. ( ) D T F d Front Rear
100, 150, 220, 330, 390, 470, 560 8.0
B 680, 820 10.0
1000 10.0
1000 7.0
1500 9.0
6.0 7.5 0.60
SC E 1800, 2200 10.0
(10.0)
3300, 3900 12.0
4700 14.0
4700 10.0
Fz 6800 14.0
10000 14.0
B 100, 150, 220, 390, 470 8.0
1000 8.0
1500 9.0
SD 7.0 10.0 0.60
E 2200 12.0
3300, 3900 14.0
4700 15.0
SAMWHA CAPACITOR Co., Ltd.
Ceramic Type
Safety Standard Recognized Ceramic Capacitors
Design
Taping Specification
Item Code
FF7 FF8
Body Diameter D 6.3 D 14.0 15.0 D 20.0
Body Thickness T 6.0Max.
Lead Diameter d 0.6-0.8 0.05
Pitch of sprocket Hole P0 15.0 0.3
Pitch of Component P 15.0 1.0 30.0 1.0
Lead Length from Hole Center Lead P1 3.75 1.0
Lead Length from Hole
P2 7.5 1.5
Center to Component Center
Lead Spacing F 7.5 1.0
Deviation Along Tape S 0 1.0
Deviation Across Tape h 0 2.0
Carrier Tape Width W 18.0
Hold Down Tape Width W0 5.0Min.
Position of Sprocket Hole W1 9.0 0.5
Hold Down Tape Position W2 3.0Max.
Lead Wire Clinch Height H0 16.0 0.5
Heighr of Component Height H 20.0
Diameter of Sprocket Hole D0 4.0 0.2
Length of Snipped Lead L 11.0Max.
Total Tape Thickness t 0.7 0.2
Lead Wire Protrtsion Lx 1.0Max.
UL File No. E97754 UL File No. E97754
VDE File No. 40015805 VDE File No. 40015804
SEMKO File No. 0215162/01-04 SEMKO File No. 0215162/01-04
FIMKO File No. 2010006 FIMKO File No. 2010006
KTL File No. SU03004-2002A KTL File No. SU03004-2001A
DEMKO File No. 311353-02 DEMKO File No. 311353-02
CSA File No. 1577876 CSA File No. 1577876
NEMKO File No. P02100817 NEMKO File No. P02100817
DISC Ceramic Capacitors
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
