Samyoung [bi-polar radial] KSA Series


>> Download Samyoung [bi-polar radial] KSA Series documenatation <<

Text preview - extract from the document
          MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS


          KSA Series                                  105 1,000Hrs assured.

       Bi-polarized.                                                                                          Solvent-
       High ripple capability.                                                                                 proof
       For Horizontal Deflection Circuit, CRT TV/MT
       RoHS compliant.
       Halogen-free capacitors are also available.
                                                                                                   SSA                        KSA
                                                                                                              Wide temp.


SPECIFICATIONS
                      Item                                                                                    Characteristics
        Rated Voltage Range                                                                                      25, 50 VDC
      Operating Temperature Range                                                                             -55 ~ +105
          Nominal Capacitance                                   2.2(F)             3.3(F)              4.7(F)              6.8(F)               8.2(F)            10(F)
     Case size D
