Image preview - the first page of the document



>> Download Samyoung [polymer smd] ARV Series documenatation <<

Text preview - extract from the document

                                                           CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS


     reALcapTM         ARV Series
        Stable Leakage Current Characteristics at SV
        (after Reflow)
        Low ESR (at 100kHz~300kHz)
                                                                ASV                       ARV
        Endurance 105, 2,000hrs                                 Stable Leakage Current
                                                           Characteristics at SV(after Reflow)
SPECIFICATIONS
             Item                                                                    Characteristics




                                                                                                                                                            Conduc ve Po ymer
                                                                                                                                                            Conducttiive Pollymer
  Category temperature range                                                          -55 to +105
      Rated voltage range                                                               16 to 20VDC
                                       Rated Voltage(WV)               16            20
         Surge voltage
                                       Surge Voltage(SV)              18.4           23.0
     Capacitance tolerance
