Image preview - the first page of the document



>> Download Samyoung [radial thru-hole] MHA Series documenatation <<

Text preview - extract from the document

       MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS


      MHA Series                  85 2,000Hrs assured

      Non-solvent proof.
      Downsized of SHL series.
      For Digital Household Appliance
      RoHS compliant.
      Halogen-free capacitors are also available.                                        SHL                          MHA
                                                                                                  Downsized
SPECIFICATIONS
           Item                                                                                           Characteristics

 Rated Voltage Range                                                  6.3     ~    100 VDC                                                   160   ~       500 VDC
Opertating Temperature Range                                            -40 ~ +85                                                              -25 ~ +85
  Capacitance Tolerance
