Image preview - the first page of the document



>> Download Samyoung [radial thru-hole] GSA (SRA) LL Series documenatation <<

Text preview - extract from the document

       MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS


    GSA(SRA)-LL Series          85      2,000Hrs assured.

   Non-solvent proof.            RoHS compliant.                            GSA                         GSA(SRA)
   Height 7mm.                   Halogen-free capacitors are                                              -LL
   Low leakage current.          also available.                             Low Leakage current
   For CAR-Audio

           LL Series            85      2,000Hrs assured.

   Non-solvent proof.        RoHS compliant.                                SHL                                LL
   Very low leakage current. Halogen-free capacitors are
   For CAR-Audio             also available.                                 Low Leakage current


SPECIFICATIONS
            Item                                                                            Characteristics
  Rated Voltage Range                                                                        6.3 ~ 100 VDC
 Operating Temperature Range                                                                 -40 ~ +85
  Capacitance Tolerance
